UNC Taps

Descriptions

Type of Thread
Unified coarse thread
Tap Tolerance
Class 2 for 2B fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper, second, bottom

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	TPI	Overall Length (mm)	Thread Length (mm)	Square Section (mm)	Pack Qty	Packaged In/On	Price
5541-0004	HSS UNC SET No.4 ISO529 TAPSET Brooke	No.4	Set(3)	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00041	HSS UNC TPR No.4 Brooke	No.4	Taper	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00042	HSS UNC SEC No.4 ISO529 TAP Brooke	No.4	Second	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00043	HSS UNC BOT No.4 ISO529 TAP Brooke	No.4	Bottom	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-0005	HSS UNC SET No.5 Brooke	No.5	Set(3)	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00051	HSS UNC TPR No.5 Brooke	No.5	Taper	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00052	HSS UNC SEC No.5 Brooke	No.5	Second	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-00053	HSS UNC BOT No.5 ISO529 TAP Brooke	No.5	Bottom	40	48	11	2.5	1	Box	You need to be logged in to see prices.
5541-0006	HSS UNC SET No.6 ISO529 TAPSET Brooke	No.6	Set(3)	32	50	13	2.8	1	Box	You need to be logged in to see prices.
5541-00061	HSS UNC TPR No.6 Brooke	No.6	Taper	32	50	13	2.8	1	Box	You need to be logged in to see prices.
5541-00062	HSS UNC SEC No.6 ISO529 TAP Brooke	No.6	Second	32	50	13	2.8	1	Box	You need to be logged in to see prices.
5541-00063	HSS UNC BOT No.6 ISO529 TAP Brooke	No.6	Bottom	32	50	13	2.8	1	Box	You need to be logged in to see prices.
5541-0008	HSS UNC SET No.8 ISO529 TAPSET Brooke	No.8	Set(3)	32	53	13	3.55	1	Box	You need to be logged in to see prices.
5541-00081	HSS UNC TPR No.8 ISO529 TAP Brooke	No.8	Taper	32	53	13	3.55	1	Box	You need to be logged in to see prices.
5541-00082	HSS UNC SEC No.8 ISO529 TAP Brooke	No.8	Second	32	53	13	3.55	1	Box	You need to be logged in to see prices.
5541-00083	HSS UNC BOT No.8 ISO529 TAP Brooke	No.8	Bottom	32	53	13	3.55	1	Box	You need to be logged in to see prices.
5541-0010	HSS UNC SET No.10 x 24 (3/16) ISO529 TAPSET Brooke	No.10	Set(3)	24	58	16	4	1	Box	You need to be logged in to see prices.
5541-00101	HSS UNC TPR No.10 x 24 (3/16) ISO529 TAP Brooke	No.10	Taper	24	58	16	4	1	Box	You need to be logged in to see prices.
5541-00102	HSS UNC SEC No.10 x 24 (3/16) ISO529 TAP Brooke	No.10	Second	24	58	16	4	1	Box	You need to be logged in to see prices.
5541-00103	HSS UNC BOT No.10 x 24 (3/16) ISO529 TAP Brooke	No.10	Bottom	24	58	16	4	1	Box	You need to be logged in to see prices.
5541-0012	HSS UNC SET No.12 ISO529 TAPSET Brooke	No.12	Set(3)	24	62	17	4.5	1	Box	You need to be logged in to see prices.
5541-00121	HSS UNC TPR No.12 ISO529 TAP Brooke	No.12	Taper	24	62	17	4.5	1	Box	You need to be logged in to see prices.
5541-00122	HSS UNC SEC No.12 ISO529 TAP Brooke	No.12	Second	24	62	17	4.5	1	Box	You need to be logged in to see prices.
5541-00123	HSS UNC BOT No.12 Brooke	No.12	Bottom	24	62	17	4.5	1	Box	You need to be logged in to see prices.
5541-0016	HSS UNC SET 1/4 ISO529 TAPSET Brooke	1/4"	Set(3)	20	66	19	5	1	Box	You need to be logged in to see prices.
5541-00161	HSS UNC TPR 1/4 ISO529 TAP Brooke	1/4"	Taper	20	66	19	5	1	Box	You need to be logged in to see prices.
5541-00162	HSS UNC SEC 1/4 ISO529 TAP Brooke	1/4"	Second	20	66	19	5	1	Box	You need to be logged in to see prices.
5541-00163	HSS UNC BOT 1/4 ISO529 TAP Brooke	1/4"	Bottom	20	66	19	5	1	Box	You need to be logged in to see prices.
5541-0020	HSS UNC SET 5/16 ISO529 TAPSET Brooke	5/16"	Set(3)	18	72	22	6.3	1	Box	You need to be logged in to see prices.
5541-00201	HSS UNC TPR 5/16 ISO529 TAP Brooke	5/16"	Taper	18	72	22	6.3	1	Box	You need to be logged in to see prices.
5541-00202	HSS UNC SEC 5/16 ISO529 TAP Brooke	5/16"	Second	18	72	22	6.3	1	Box	You need to be logged in to see prices.
5541-00203	HSS UNC BOT 5/16 ISO529 TAP Brooke	5/16"	Bottom	18	72	22	6.3	1	Box	You need to be logged in to see prices.
5541-0024	HSS UNC SET 3/8 ISO529 TAPSET Brooke	3/8"	Set(3)	16	80	24	8	1	Box	You need to be logged in to see prices.
5541-00241	HSS UNC TPR 3/8 ISO529 TAP Brooke	3/8"	Taper	16	80	24	8	1	Box	You need to be logged in to see prices.
5541-00242	HSS UNC SEC 3/8 ISO529 TAP Brooke	3/8"	Second	16	80	24	8	1	Box	You need to be logged in to see prices.
5541-00243	HSS UNC BOT 3/8 ISO529 TAP Brooke	3/8"	Bottom	16	80	24	8	1	Box	You need to be logged in to see prices.
5541-0028	HSS UNC SET 7/16 ISO529 TAPSET Brooke	7/16"	Set(3)	14	85	25	6.3	1	Box	You need to be logged in to see prices.
5541-00281	HSS UNC TPR 7/16 ISO529 TAP Brooke	7/16"	Taper	14	85	25	6.3	1	Box	You need to be logged in to see prices.
5541-00282	HSS UNC SEC 7/16 ISO529 TAP Brooke	7/16"	Second	14	85	25	6.3	1	Box	You need to be logged in to see prices.
5541-00283	HSS UNC BOT 7/16 ISO529 TAP Brooke	7/16"	Bottom	14	85	25	6.3	1	Box	You need to be logged in to see prices.
5541-0032	HSS UNC SET 1/2 ISO529 TAPSET Brooke	1/2"	Set(3)	13	89	29	7.1	1	Box	You need to be logged in to see prices.
5541-00321	HSS UNC TPR 1/2 ISO529 TAP Brooke	1/2"	Taper	13	89	29	7.1	1	Box	You need to be logged in to see prices.
5541-00322	HSS UNC SEC 1/2 ISO529 TAP Brooke	1/2"	Second	13	89	29	7.1	1	Box	You need to be logged in to see prices.
5541-00323	HSS UNC BOT 1/2 ISO529 TAP Brooke	1/2"	Bottom	13	89	29	7.1	1	Box	You need to be logged in to see prices.
5541-0036	HSS UNC SET 9/16 ISO529 TAPSET Brooke	9/16"	Set(3)	12	95	30	9	1	Box	You need to be logged in to see prices.
5541-00361	HSS UNC TPR 9/16 ISO529 TAP Brooke	9/16"	Taper	12	95	30	9	1	Box	You need to be logged in to see prices.
5541-00362	HSS UNC SEC 9/16 ISO529 TAP Brooke	9/16"	Second	12	95	30	9	1	Box	You need to be logged in to see prices.
5541-00363	HSS UNC BOT 9/16 ISO529 TAP Brooke	9/16"	Bottom	12	95	30	9	1	Box	You need to be logged in to see prices.
5541-0040	HSS UNC SET 5/8 ISO529 TAPSET Brooke	5/8"	Set(3)	11	102	32	10	1	Box	You need to be logged in to see prices.
5541-00401	HSS UNC TPR 5/8 ISO529 TAP Brooke	5/8"	Taper	11	102	32	10	1	Box	You need to be logged in to see prices.
5541-00402	HSS UNC SEC 5/8 ISO529 TAP Brooke	5/8"	Second	11	102	32	10	1	Box	You need to be logged in to see prices.
5541-00403	HSS UNC BOT 5/8 ISO529 TAP Brooke	5/8"	Bottom	11	102	32	10	1	Box	You need to be logged in to see prices.
5541-0048	HSS UNC SET 3/4 ISO529 TAPSET Brooke	3/4"	Set(3)	10	112	37	11.2	1	Box	You need to be logged in to see prices.
5541-00481	HSS UNC TPR 3/4 ISO529 TAP Brooke	3/4"	Taper	10	112	37	11.2	1	Box	You need to be logged in to see prices.
5541-00482	HSS UNC SEC 3/4 ISO529 TAP Brooke	3/4"	Second	10	112	37	11.2	1	Box	You need to be logged in to see prices.
5541-00483	HSS UNC BOT 3/4 ISO529 TAP Brooke	3/4"	Bottom	10	112	37	11.2	1	Box	You need to be logged in to see prices.
5541-0056	HSS UNC SET 7/8 ISO529 TAPSET Brooke	7/8"	Set(3)	9	118	38	12.5	1	Box	You need to be logged in to see prices.
5541-00561	HSS UNC TPR 7/8 ISO529 TAP Brooke	7/8"	Taper	9	118	38	12.5	1	Box	You need to be logged in to see prices.
5541-00562	HSS UNC SEC 7/8 ISO529 TAP Brooke	7/8"	Second	9	118	38	12.5	1	Box	You need to be logged in to see prices.
5541-00563	HSS UNC BOT 7/8 ISO529 TAP Brooke	7/8"	Bottom	9	118	38	12.5	1	Box	You need to be logged in to see prices.
5541-0100	HSS UNC SET 1 inch ISO529 TAPSET Brooke	1"	Set(3)	8	130	45	14	1	Box	You need to be logged in to see prices.
5541-01001	HSS UNC TPR 1 inch ISO529 TAP Brooke	1"	Taper	8	130	45	14	1	Box	You need to be logged in to see prices.
5541-01002	HSS UNC SEC 1 inch ISO529 TAP Brooke	1"	Second	8	130	45	14	1	Box	You need to be logged in to see prices.
5541-01003	HSS UNC BOT 1 inch ISO529 TAP Brooke	1"	Bottom	8	130	45	14	1	Box	You need to be logged in to see prices.
5541-0108	HSS UNC SET 1.1/8 ISO529 TAPSET Brooke	1.1/8"	Set(3)	7	138	48	16	1	Box	You need to be logged in to see prices.
5541-01081	HSS UNC TPR 1.1/8 Brooke	1.1/8"	Taper	7	138	48	16	1	Box	You need to be logged in to see prices.
5541-01082	HSS UNC SEC 1.1/8 Brooke	1.1/8"	Second	7	138	48	16	1	Box	You need to be logged in to see prices.
5541-01083	HSS UNC BOT 1.1/8 ISO529 TAP Brooke	1.1/8"	Bottom	7	138	48	16	1	Box	You need to be logged in to see prices.
