SDS Plus Quad Tip Hammer Drill Bits

Flute Type
Right hand
Surface finish
Silver-grey finish

Shank Type
SDS plus
Appropriate For
All rotary hammers with SDS plus holder
Application
For drilling holes in masonry, concrete, reinforced concrete, limestone, natural stone & artificial stone.SDS Plus Quad drill bits have a more aggressive drill rate, drills more holes than a standard SDS Plus drill bit, head geometry ensures precision drilled holes and is able to drill at higher speeds.
Tip Material
Tungsten carbide quad tip

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C234-050110 5.0mm x 110mm Quad Tip SDS Plus Drill 5.0mm 50 110 1 Euro hanger
C234-050160 5.0mm x 160mm Quad Tip SDS Plus Drill 5.0mm 100 160 1 Euro hanger
C234-055160 5.5mm x 160mm Quad Tip SDS Plus Drill 5.5mm 100 160 1 Euro hanger
C234-060110 6.0mm x 110mm Quad Tip SDS Plus Drill 6.0mm 50 110 1 Euro hanger
C234-060160 6.0mm x 160mm Quad Tip SDS Plus Drill 6.0mm 100 160 1 Euro hanger
C234-060210 6.0mm x 210mm Quad Tip SDS Plus Drill 6.0mm 150 210 1 Euro hanger
C234-060260 6.0mm x 260mm Quad Tip SDS Plus Drill 6.0mm 200 260 1 Euro hanger
C234-065210 6.5mm x 210mm Quad Tip SDS Plus Drill 6.5mm 150 210 1 Euro hanger
C234-070160 7.0mm x 160mm Quad Tip SDS Plus Drill 7.0mm 100 160 1 Euro hanger
C234-070210 7.0mm x 210mm Quad Tip SDS Plus Drill 7.0mm 150 210 1 Euro hanger
C234-080160 8.0mm x 160mm Quad Tip SDS Plus Drill 8.0mm 100 160 1 Euro hanger
C234-080210 8.0mm x 210mm Quad Tip SDS Plus Drill 8.0mm 150 210 1 Euro hanger
C234-080260 8.0mm x 260mm Quad Tip SDS Plus Drill 8.0mm 200 260 1 Euro hanger
C234-100160 10.0mm x 160mm Quad Tip SDS Plus Drill 10.0mm 100 160 1 Euro hanger
C234-100210 10.0mm x 210mm Quad Tip SDS Plus Drill 10.0mm 150 210 1 Euro hanger
C234-100260 10.0mm x 260mm Quad Tip SDS Plus Drill 10.0mm 200 260 1 Euro hanger
C234-120160 12.0mm x 160mm Quad Tip SDS Plus Drill 12.0mm 100 160 1 Euro hanger
C234-120210 12.0mm x 210mm Quad Tip SDS Plus Drill 12.0mm 150 210 1 Euro hanger
C234-160460 16.0mm x 460mm Quad Tip SDS Plus Drill 16.0mm 400 460 1 Euro hanger
C234-180460 18.0mm x 460mm Quad Tip SDS Plus Drill 18.0mm 400 460 1 Euro hanger
C234-200460 20.0mm x 460mm Quad Tip SDS Plus Drill 20.0mm 400 460 1 Euro hanger
C234-220460 22.0mm x 460mm Quad Tip SDS Plus Drill 22.0mm 400 460 1 Euro hanger
C234-250460 25.0mm x 460mm Quad Tip SDS Plus Drill 25.0mm 400 460 1 Euro hanger
C234-020002SET 8PCS SDS+ Set PT,CH,WCx250mm QT 5.5,6,7x160mm 8,10x210mm Point 250mm, chisel 20x250mm, wide chisel 40x250mm, drill bits, 5.5, 6, 7x160mm, 8, 10x210mm 1 Euro hanger case
