NPT Taps
NPT Taps

NPT Taps

Descriptions

Type of Thread
American taper pipe thread form
Tap Tolerance
ANSI B94.9 - 1979
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 2284
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter TPI Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5585-00083 HSS NPT Plug 1/8 X 27 TW2 ISO529 TAP Brooke 1/8" 1/8" 59 15 6.3 1 Box
You need to be logged in to see prices.
5585-00163 HSS NPT Plug 1/4 x 18 TW3 ISO529 TAP Brooke 1/4" 1/4" 67 19 8 1 Box
You need to be logged in to see prices.
5585-00243 HSS NPT Plug 3/8 x 18 TW4 ISO529 TAP Brooke 3/8" 3/8" 75 21 10 1 Box
You need to be logged in to see prices.
5585-00323 HSS NPT Plug 1/2 x 14 TW5 ISO529 TAP Brooke 1/2" 1/2" 87 26 12.5 1 Box
You need to be logged in to see prices.
5585-00483 HSS NPT Plug 3/4 x 14 TW5 ISO529 TAP Brooke 3/4" 3/4" 86 28 16 1 Box
You need to be logged in to see prices.
5585-01003 HSS NPT Plug 1"x11.1/2" TW6 ISO529 TAP Brooke 1" 1" 109 33 20 1 Box
You need to be logged in to see prices.
