Metric Fine Taps

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper, second, bottom

Specifications

Downloads

There are no downloads for this product.

You need to be logged in to see prices.

Code	Description	Diameter	Type	Pitch (mm)	Overall Length (mm)	Thread Length (mm)	Square Section (mm)	Pack Qty	Packaged In/On	Price
5511-0040	HSS MF4.0 x0.50 SET ISO529 TAPSET Brooke	M4	Set(3)	0.5	53	13	3.15	1	Box	You need to be logged in to see prices.
5511-00401	HSS MF4.0 x0.50 TPR ISO 529 TAP Brooke	M4	Taper	0.5	53	13	3.15	1	Box	You need to be logged in to see prices.
5511-00402	HSS MF4.0 x0.50 SEC ISO 529 TAP Brooke	M4	Second	0.5	53	13	3.15	1	Box	You need to be logged in to see prices.
5511-00403	HSS MF4.0 x0.50 BOT ISO529 TAP Brooke	M4	Bottom	0.5	53	13	3.15	1	Box	You need to be logged in to see prices.
5511-0050	HSS MF5.0 x0.50 SET ISO529 TAPSET Brooke	M5	Set(3)	0.5	58	16	4	1	Box	You need to be logged in to see prices.
5511-00501	HSS MF5.0 x0.50 TPR ISO529 TAP Brooke	M5	Taper	0.5	58	16	4	1	Box	You need to be logged in to see prices.
5511-00502	HSS MF5.0 x0.50 SEC ISO529 TAP Brooke	M5	Second	0.5	58	16	4	1	Box	You need to be logged in to see prices.
5511-00503	HSS MF5.0 x0.50 BOT ISO529 TAP Brooke	M5	Bottom	0.5	58	16	4	1	Box	You need to be logged in to see prices.
5511-0060	HSS MF6.0 x0.75 SET ISO529 TAPSET Brooke	M6	Set(3)	0.75	66	19	5	1	Box	You need to be logged in to see prices.
5511-00601	HSS MF6.0 x0.75 TPR ISO529 TAP Brooke	M6	Taper	0.75	66	19	5	1	Box	You need to be logged in to see prices.
5511-00602	HSS MF6.0 x0.75 SEC ISO529 TAP Brooke	M6	Second	0.75	66	19	5	1	Box	You need to be logged in to see prices.
5511-00603	HSS MF6.0 x0.75 BOT ISO529 TAP Brooke	M6	Bottom	0.75	66	19	5	1	Box	You need to be logged in to see prices.
5511-0080	HSS MF8.0 x0.75 SET ISO529 TAPSET Brooke	M8	Set(3)	0.75	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00801	HSS MF8.0 x0.75 TPR ISO529 TAP Brooke	M8	Taper	0.75	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00802	HSS MF8.0 x0.75 SEC ISO529 TAP Brooke	M8	Second	0.75	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00803	HSS MF8.0 x0.75 BOT ISO529 TAP Brooke	M8	Bottom	0.75	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-0081	HSS MF8.0 x1.00 SET ISO529 TAPSET Brooke	M8	Set(3)	1	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00811	HSS MF8.0 x1.00 TPR ISO529 TAP Brooke	M8	Taper	1	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00812	HSS MF8.0 x1.00 SEC ISO529 TAP Brooke	M8	Second	1	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-00813	HSS MF8.0 x1.00 BOT ISO529 TAP Brooke	M8	Bottom	1	69	19	6.3	1	Box	You need to be logged in to see prices.
5511-0110	HSS MF10.0 x1.00 SET ISO529 TAPSET Brooke	M10	Set(3)	1	76	20	8	1	Box	You need to be logged in to see prices.
5511-01101	HSS MF10.0 x1.00 TPR ISO529 TAP Brooke	M10	Taper	1	76	20	8	1	Box	You need to be logged in to see prices.
5511-01102	HSS MF10.0 x1.00 SEC ISO529 TAP Brooke	M10	Second	1	76	20	8	1	Box	You need to be logged in to see prices.
5511-01103	HSS MF10.0 x1.00 BOT ISO529 TAP Brooke	M10	Bottom	1	76	20	8	1	Box	You need to be logged in to see prices.
5511-0112	HSS MF10.0 x1.25 SET ISO529 TAPSET Brooke	M10	Set(3)	1.25	76	20	8	1	Box	You need to be logged in to see prices.
5511-01121	HSS MF10.0 x1.25 TPR ISO529 TAP Brooke	M10	Taper	1.25	76	20	8	1	Box	You need to be logged in to see prices.
5511-01122	HSS MF10.0 x1.25 SEC ISO529 TAP Brooke	M10	Second	1.25	76	20	8	1	Box	You need to be logged in to see prices.
5511-01123	HSS MF10.0 x1.25 BOT ISO529 TAP Brooke	M10	Bottom	1.25	76	20	8	1	Box	You need to be logged in to see prices.
5511-0120	HSS MF12.0 x1.00 SET ISO529 TAPSET Brooke	M12	Set(3)	1	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01201	HSS MF12.0 x1.00 TPR ISO529 TAP Brooke	M12	Taper	1	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01202	HSS MF12.0 x1.00 SEC ISO529 TAP Brooke	M12	Second	1	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01203	HSS MF12.0 x1.00 BOT ISO529 TAP Brooke	M12	Bottom	1	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-0121	HSS MF12.0 x1.25 SET ISO529 TAPSET Brooke	M12	Set(3)	1.25	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01211	HSS MF12.0 x1.25 TPR ISO529 TAP Brooke	M12	Taper	1.25	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01212	HSS MF12.0 x1.25 SEC ISO529 TAP Brooke	M12	Second	1.25	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-01213	HSS MF12.0 x1.25 BOT ISO529 TAP Brooke	M12	Bottom	1.25	84	24	7.1	1	Box	You need to be logged in to see prices.
5511-0122	HSS MF12.0 x1.50 SET ISO529 TAPSET Brooke	M12	Set(3)	1.5	89	29	7.1	1	Box	You need to be logged in to see prices.
5511-01221	HSS MF12.0 x1.50 TPR ISO529 TAP Brooke	M12	Taper	1.5	89	29	7.1	1	Box	You need to be logged in to see prices.
5511-01222	HSS MF12.0 x1.50 SEC ISO529 TAP Brooke	M12	Second	1.5	89	29	7.1	1	Box	You need to be logged in to see prices.
5511-01223	HSS MF12.0 x1.50 BOT ISO529 TAP Brooke	M12	Bottom	1.5	89	29	7.1	1	Box	You need to be logged in to see prices.
5511-0140	HSS MF14.0 x1.00 SET ISO529 TAPSET Brooke	M14	Set(3)	1	90	25	9	1	Box	You need to be logged in to see prices.
5511-01401	HSS MF14.0 x1.00 TPR ISO529 TAP Brooke	M14	Taper	1	90	25	9	1	Box	You need to be logged in to see prices.
5511-01402	HSS MF14.0 x1.00 SEC ISO529 TAP Brooke	M14	Second	1	90	25	9	1	Box	You need to be logged in to see prices.
5511-01403	HSS MF14.0 x1.00 BOT ISO529 TAP Brooke	M14	Bottom	1	90	25	9	1	Box	You need to be logged in to see prices.
5511-0141	HSS MF14.0 x1.25 SET ISO529 TAPSET Brooke	M14	Set(3)	1.25	90	25	9	1	Box	You need to be logged in to see prices.
5511-01411	HSS MF14.0 x1.25 TPR ISO529 TAP Brooke	M14	Taper	1.25	90	25	9	1	Box	You need to be logged in to see prices.
5511-01412	HSS MF14.0 x1.25 SEC ISO529 TAP Brooke	M14	Second	1.25	90	25	9	1	Box	You need to be logged in to see prices.
5511-01413	HSS MF14.0 x1.25 BOT ISO529 TAP Brooke	M14	Bottom	1.25	90	25	9	1	Box	You need to be logged in to see prices.
5511-0142	HSS MF14.0 x1.50 SET ISO529 TAPSET Brooke	M14	Set(3)	1.5	95	30	9	1	Box	You need to be logged in to see prices.
5511-01421	HSS MF14.0 x1.50 TPR ISO529 TAP Brooke	M14	Taper	1.5	95	30	9	1	Box	You need to be logged in to see prices.
5511-01422	HSS MF14.0 x1.50 SEC ISO529 TAP Brooke	M14	Second	1.5	95	30	9	1	Box	You need to be logged in to see prices.
5511-01423	HSS MF14.0 x1.50 BOT ISO529 TAP Brooke	M14	Bottom	1.5	95	30	9	1	Box	You need to be logged in to see prices.
5511-0160	HSS MF16.0 x1.00 SET ISO529 TAPSET Brooke	M16	Set(3)	1	95	25	10	1	Box	You need to be logged in to see prices.
5511-01601	HSS MF16.0 x1.00 TPR ISO529 TAP Brooke	M16	Taper	1	95	25	10	1	Box	You need to be logged in to see prices.
5511-01602	HSS MF16.0 x1.00 SEC ISO529 TAP Brooke	M16	Second	1	95	25	10	1	Box	You need to be logged in to see prices.
5511-01603	HSS MF16.0 x1.00 BOT ISO529 TAP Brooke	M16	Bottom	1	95	25	10	1	Box	You need to be logged in to see prices.
5511-0162	HSS MF16.0 x1.50 SET ISO529 TAPSET Brooke	M16	Set(3)	1.5	102	25	10	1	Box	You need to be logged in to see prices.
5511-01621	HSS MF16.0 x1.50 TPR ISO529 TAP Brooke	M16	Taper	1.5	102	25	10	1	Box	You need to be logged in to see prices.
5511-01622	HSS MF16.0 x1.50 SEC ISO529 TAP Brooke	M16	Second	1.5	102	25	10	1	Box	You need to be logged in to see prices.
5511-01623	HSS MF16.0 x1.50 BOT ISO529 TAP Brooke	M16	Bottom	1.5	102	25	10	1	Box	You need to be logged in to see prices.
5511-0180	HSS MF18.0 x1.00 SET ISO529 TAPSET Brooke	M18	Set(3)	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01801	HSS MF18.0 x1.00 TPR ISO529 TAP Brooke	M18	Taper	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01802	HSS MF18.0 x1.00 SEC ISO529 TAP Brooke	M18	Second	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01803	HSS MF18.0 x1.00 BOT ISO529 TAP Brooke	M18	Bottom	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-0181	HSS MF18.0 x1.50 SET ISO529 TAPSET Brooke	M18	Set(3)	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01811	HSS MF18.0 x1.50 TPR ISO529 TAP Brooke	M18	Taper	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01812	HSS MF18.0 x1.50 SEC ISO529 TAP Brooke	M18	Second	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-01813	HSS MF18.0 x1.50 BOT ISO529 TAP Brooke	M18	Bottom	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-0182	HSS MF18.0 x2.00 SET ISO529 TAPSET Brooke	M18	Set(3)	2	112	37	11.2	1	Box	You need to be logged in to see prices.
5511-01821	HSS MF18.0 x2.00 TPR ISO529 TAP Brooke	M18	Taper	2	112	37	11.2	1	Box	You need to be logged in to see prices.
5511-01822	HSS MF18.0 x2.00 SEC ISO529 TAP Brooke	M18	Second	2	112	37	11.2	1	Box	You need to be logged in to see prices.
5511-01823	HSS MF18.0 x2.00 BOT ISO529 TAP Brooke	M18	Bottom	2	112	37	11.2	1	Box	You need to be logged in to see prices.
5511-0200	HSS MF20.0 x1.00 SET ISO529 TAPSET Brooke	M20	Set(3)	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02001	HSS MF20.0 x1.00 TPR ISO529 TAP Brooke	M20	Taper	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02002	HSS MF20.0 x1.00 SEC ISO529 TAP Brooke	M20	Second	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02003	HSS MF20.0 x1.00 BOT ISO529 TAP Brooke	M20	Bottom	1	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-0201	HSS MF20.0 x1.50 SET ISO529 TAPSET Brooke	M20	Set(3)	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02011	HSS MF20.0 x1.50 TPR ISO529 TAP Brooke	M20	Taper	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02012	HSS MF20.0 x1.50 SEC ISO529 TAP Brooke	M20	Second	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-02013	HSS MF20.0 x1.50 BOT ISO529 TAP Brooke	M20	Bottom	1.5	104	29	11.2	1	Box	You need to be logged in to see prices.
5511-0241	HSS MF24.0 x1.50 SET ISO529 TAPSET Brooke	M24	Set(3)	1.5	120	35	14	1	Box	You need to be logged in to see prices.
5511-02411	HSS MF24.0 x1.50 TPR ISO529 TAP Brooke	M24	Taper	1.5	120	35	14	1	Box	You need to be logged in to see prices.
5511-02412	HSS MF24.0 x1.50 SEC ISO529 TAP Brooke	M24	Second	1.5	120	35	14	1	Box	You need to be logged in to see prices.
5511-02413	HSS MF24.0 x1.50 BOT ISO529 TAP Brooke	M24	Bottom	1.5	120	35	14	1	Box	You need to be logged in to see prices.
5511-0242	HSS MF24.0 x2.00 SET ISO529 TAPSET Brooke	M24	Set(3)	2	120	35	14	1	Box	You need to be logged in to see prices.
5511-02421	HSS MF24.0 x2.00 TPR ISO529 TAP Brooke	M24	Taper	2	120	35	14	1	Box	You need to be logged in to see prices.
5511-02422	HSS MF24.0 x2.00 SEC ISO529 TAP Brooke	M24	Second	2	120	35	14	1	Box	You need to be logged in to see prices.
5511-02423	HSS MF24.0 x2.00 BOT ISO529 TAP Brooke	M24	Bottom	2		35	14	1	Box	You need to be logged in to see prices.

You need to be logged in to see prices.
