Metric Coarse Taps
Metric Coarse Taps
Metric Coarse Taps

Metric Coarse Taps

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSS
Set Consists of
Taper, second, bottom

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Type Pitch (mm) Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5501-0020 HSS MC2.0x.40 SET TAP ISO 529 Brooke M2 Set(3) 0.4 41 8 2 1 Box
You need to be logged in to see prices.
5501-00201 HSS MC2.0x.40 TAPER TAP ISO 529 Brooke M2 Taper 0.4 41 8 2 1 Box
You need to be logged in to see prices.
5501-00202 HSS MC2.0x.40 SECOND TAP ISO 529 Brooke M2 Second 0.4 41 8 2 1 Box
You need to be logged in to see prices.
5501-00203 HSS MC2.0x.40 BOTT'G TAP ISO 529 Brooke M2 Bottom 0.4 41 8 2 1 Box
You need to be logged in to see prices.
5501-0025 HSS MC2.5x.45 SET TAP ISO 529 Brooke M2.5 Set(3) 0.45 44.5 9.5 2.24 1 Box
You need to be logged in to see prices.
5501-00251 HSS MC2.5x.45 TAPER TAP ISO 529 Brooke M2.5 Taper 0.45 44.5 9.5 2.24 1 Box
You need to be logged in to see prices.
5501-00252 HSS MC2.5x.45 SECOND TAP ISO 529 Brooke M2.5 Second 0.45 44.5 9.5 2.24 1 Box
You need to be logged in to see prices.
5501-00253 HSS MC2.5x.45 BOTT'G TAP ISO 529 Brooke M2.5 Bottom 0.45 44.5 9.5 2.24 1 Box
You need to be logged in to see prices.
5501-0030 HSS MC3.0x.50 SET TAP ISO 529 Brooke M3 Set(3) 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5501-00301 HSS MC3.0x.50 TAPER TAP ISO 529 Brooke M3 Taper 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5501-00302 HSS MC3.0x.50 SECOND TAP ISO 529 Brooke M3 Second 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5501-00303 HSS MC3.0x.50 BOTT'G TAP ISO 529 Brooke M3 Bottom 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5501-0035 HSS MC3.5x.60 SET TAP ISO 529 Brooke M3.5 Set(3) 0.6 50 13 2.8 1 Box
You need to be logged in to see prices.
5501-00351 HSS MC3.5x.60 TAPER TAP ISO 529 Brooke M3.5 Taper 0.6 50 13 2.8 1 Box
You need to be logged in to see prices.
5501-00352 HSS MC3.5x.60 SECOND TAP ISO 529 Brooke M3.5 Second 0.6 50 13 2.8 1 Box
You need to be logged in to see prices.
5501-00353 HSS MC3.5x.60 BOTT'G TAP ISO 529 Brooke M3.5 Bottom 0.6 50 13 2.8 1 Box
You need to be logged in to see prices.
5501-0040 HSS MC4.0x.70 SET TAP ISO 529 Brooke M4 Set(3) 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5501-00401 HSS MC4.0x.70 TAPER TAP ISO 529 Brooke M4 Taper 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5501-00402 HSS MC4.0x.70 SECOND TAP ISO 529 Brooke M4 Second 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5501-00403 HSS MC4.0x.70 BOTT'G TAP ISO 529 Brooke M4 Bottom 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5501-0045 HSS MC4.5x.75 SET TAP ISO 529 Brooke M4.5 Set(3) 0.75 53 13 3.55 1 Box
You need to be logged in to see prices.
5501-00451 HSS MC4.5x.75 TAPER TAP ISO 529 Brooke M4.5 Taper 0.75 53 13 3.55 1 Box
You need to be logged in to see prices.
5501-00452 HSS MC4.5x.75 SECOND TAP ISO 529 Brooke M4.5 Second 0.75 53 13 3.55 1 Box
You need to be logged in to see prices.
5501-00453 HSS MC4.5x.75 BOTT'G TAP ISO 529 Brooke M4.5 Bottom 0.75 53 13 3.55 1 Box
You need to be logged in to see prices.
5501-0050 HSS MC5.0x.80 SET TAP ISO 529 Brooke M5 Set(3) 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5501-00501 HSS MC5.0x.80 TAPER TAP ISO 529 Brooke M5 Taper 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5501-00502 HSS MC5.0x.80 SECOND TAP ISO 529 Brooke M5 Second 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5501-00503 HSS MC5.0x.80 BOTT'G TAP ISO 529 Brooke M5 Bottom 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5501-0060 HSS MC6.0x1.0 SET TAP ISO 529 Brooke M6 Set(3) 1 66 19 5 1 Box
You need to be logged in to see prices.
5501-00601 HSS MC6.0x1.0 TAPER TAP ISO 529 Brooke M6 Taper 1 66 19 5 1 Box
You need to be logged in to see prices.
5501-00602 HSS MC6.0x1.0 SECOND TAP ISO 529 Brooke M6 Second 1 66 19 5 1 Box
You need to be logged in to see prices.
5501-00603 HSS MC6.0x1.0 BOTT'G TAP ISO 529 Brooke M6 Bottom 1 66 19 5 1 Box
You need to be logged in to see prices.
5501-0070 HSS MC7.0x1.0 SET TAP ISO 529 Brooke M7 Set(3) 1 66 19 5.6 1 Box
You need to be logged in to see prices.
5501-00701 HSS MC7.0x1.0 TAPER TAP ISO 529 Brooke M7 Taper 1 66 19 5.6 1 Box
You need to be logged in to see prices.
5501-00702 HSS MC7.0x1.0 SECOND TAP ISO 529 Brooke M7 Second 1 66 19 5.6 1 Box
You need to be logged in to see prices.
5501-00703 HSS MC7.0x1.0 BOTT'G TAP ISO 529 Brooke M7 Bottom 1 66 19 5.6 1 Box
You need to be logged in to see prices.
5501-0080 HSS MC8.0x1.25 SET TAP ISO 529 Brooke M8 Set(3) 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5501-00801 HSS MC8.0x1.25 TAPER TAP ISO 529 Brooke M8 Taper 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5501-00802 HSS MC8.0x1.25 SECND TAP ISO 529 Brooke M8 Second 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5501-00803 HSS MC8.0x1.25 BOT'G TAP ISO 529 Brooke M8 Bottom 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5501-0090 HSS MC9.0x1.25 SET TAP ISO 529 Brooke M9 Set(3) 1.25 72 22 7.1 1 Box
You need to be logged in to see prices.
5501-00901 HSS MC9.0x1.25 TAPER TAP ISO 529 Brooke M9 Taper 1.25 72 22 7.1 1 Box
You need to be logged in to see prices.
5501-00902 HSS MC9.0x1.25 SECND TAP ISO 529 Brooke M9 Second 1.25 72 22 7.1 1 Box
You need to be logged in to see prices.
5501-00903 HSS MC9.0x1.25 BOT'G TAP ISO 529 Brooke M9 Bottom 1.25 72 22 7.1 1 Box
You need to be logged in to see prices.
5501-0100 HSS MC10.0x1.5 SET TAP ISO 529 Brooke M10 Set(3) 1.5 80 24 8 1 Box
You need to be logged in to see prices.
5501-01001 HSS MC10.0x1.5 TAPER TAP ISO 529 Brooke M10 Taper 1.5 80 24 8 1 Box
You need to be logged in to see prices.
5501-01002 HSS MC10.0x1.5 SECND TAP ISO 529 Brooke M10 Second 1.5 80 24 8 1 Box
You need to be logged in to see prices.
5501-01003 HSS MC10.0x1.5 BOT'G TAP ISO 529 Brooke M10 Bottom 1.5 80 24 8 1 Box
You need to be logged in to see prices.
5501-0110 HSS MC11.0x1.5 SET TAP ISO 529 Brooke M11 Set(3) 1.5 85 25 6.3 1 Box
You need to be logged in to see prices.
5501-01101 HSS MC11.0x1.5 TAPER TAP ISO 529 Brooke M11 Taper 1.5 85 25 6.3 1 Box
You need to be logged in to see prices.
5501-01102 HSS MC11.0x1.5 SECND TAP ISO 529 Brooke M11 Second 1.5 85 25 6.3 1 Box
You need to be logged in to see prices.
5501-01103 HSS MC11.0x1.5 BOT'G TAP ISO 529 Brooke M11 Bottom 1.5 85 25 6.3 1 Box
You need to be logged in to see prices.
5501-0120 HSS MC12.0x1.75 SET TAP ISO 529 Brooke M12 Set(3) 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5501-01201 HSS MC12.0x1.75 TAPR TAP ISO 529 Brooke M12 Taper 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5501-01202 HSS MC12.0x1.75 SCND TAP ISO 529 Brooke M12 Second 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5501-01203 HSS MC12.0x1.75 BOTG TAP ISO 529 Brooke M12 Bottom 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5501-0140 HSS MC14.0x2.0 SET TAP ISO 529 Brooke M14 Set(3) 2 95 30 9 1 Box
You need to be logged in to see prices.
5501-01401 HSS MC14.0x2.0 TAPER TAP ISO 529 Brooke M14 Taper 2 95 30 9 1 Box
You need to be logged in to see prices.
5501-01402 HSS MC14.0x2.0 SECND TAP ISO 529 Brooke M14 Second 2 95 30 9 1 Box
You need to be logged in to see prices.
5501-01403 HSS MC14.0x2.0 BOT'G TAP ISO 529 Brooke M14 Bottom 2 95 30 9 1 Box
You need to be logged in to see prices.
5501-0160 HSS MC16.0x2.0 SET TAP ISO 529 Brooke M16 Set(3) 2 102 32 10 1 Box
You need to be logged in to see prices.
5501-01601 HSS MC16.0x2.0 TAPER TAP ISO 529 Brooke M16 Taper 2 102 32 10 1 Box
You need to be logged in to see prices.
5501-01602 HSS MC16.0x2.0 SECND TAP ISO 529 Brooke M16 Second 2 102 32 10 1 Box
You need to be logged in to see prices.
5501-01603 HSS MC16.0x2.0 BOT'G TAP ISO 529 Brooke M16 Bottom 2 102 32 10 1 Box
You need to be logged in to see prices.
5501-0180 HSS MC18.0x2.5 SET TAP ISO 529 Brooke M18 Set(3) 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-01801 HSS MC18.0x2.5 TAPER TAP ISO 529 Brooke M18 Taper 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-01802 HSS MC18.0x2.5 SECND TAP ISO 529 Brooke M18 Second 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-01803 HSS MC18.0x2.5 BOT'G TAP ISO 529 Brooke M18 Bottom 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-0200 HSS MC20.0x2.5 SET TAP ISO 529 Brooke M20 Set(3) 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-02001 HSS MC20.0x2.5 TAPER TAP ISO 529 Brooke M20 Taper 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-02002 HSS MC20.0x2.5 SECND TAP ISO 529 Brooke M20 Second 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-02003 HSS MC20.0x2.5 BOT'G TAP ISO 529 Brooke M20 Bottom 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
5501-0220 HSS MC22.0x2.5 SET TAP ISO 529 Brooke M22 Set(3) 2.5 118 38 12.5 1 Box
You need to be logged in to see prices.
5501-02201 HSS MC22.0x2.5 TAPER TAP ISO 529 Brooke M22 Taper 2.5 118 38 12.5 1 Box
You need to be logged in to see prices.
5501-02202 HSS MC22.0x2.5 SECND TAP ISO 529 Brooke M22 Second 2.5 118 38 12.5 1 Box
You need to be logged in to see prices.
5501-02203 HSS MC22.0x2.5 BOT'G TAP ISO 529 Brooke M22 Bottom 2.5 118 38 12.5 1 Box
You need to be logged in to see prices.
5501-0240 HSS MC24.0x3.0 SET TAP ISO 529 Brooke M24 Set(3) 3 130 45 14 1 Box
You need to be logged in to see prices.
5501-02401 HSS MC24.0x3.0 TAPER TAP ISO 529 Brooke M24 Taper 3 130 45 14 1 Box
You need to be logged in to see prices.
5501-02402 HSS MC24.0x3.0 SECND TAP ISO 529 Brooke M24 Second 3 130 45 14 1 Box
You need to be logged in to see prices.
5501-02403 HSS MC24.0x3.0 BOT'G TAP ISO 529 Brooke M24 Bottom 3 130 45 14 1 Box
You need to be logged in to see prices.
5501-0270 HSS MC27.0x3.0 SET TAP ISO 529 Brooke M27 Set(3) 3 135 45 16 1 Box
You need to be logged in to see prices.
5501-02701 HSS MC27.0x3.0 TAPER TAP ISO 529 Brooke M27 Taper 3 135 45 16 1 Box
You need to be logged in to see prices.
5501-02702 HSS MC27.0x3.0 SECND TAP ISO 529 Brooke M27 Second 3 135 45 16 1 Box
You need to be logged in to see prices.
5501-02703 HSS MC27.0x3.0 BOT'G TAP ISO 529 Brooke M27 Bottom 3 135 45 16 1 Box
You need to be logged in to see prices.
5501-0300 HSS MC30.0x3.5 SET TAP ISO 529 Brooke M30 Set(3) 3.5 138 48 16 1 Box
You need to be logged in to see prices.
5501-03001 HSS MC30.0x3.5 TAPER TAP ISO 529 Brooke M30 Taper 3.5 138 48 16 1 Box
You need to be logged in to see prices.
5501-03002 HSS MC30.0x3.5 SECND TAP ISO 529 Brooke M30 Second 3.5 138 48 16 1 Box
You need to be logged in to see prices.
5501-03003 HSS MC30.0x3.5 BOT'G TAP ISO 529 Brooke M30 Bottom 3.5 138 48 16 1 Box
You need to be logged in to see prices.
5501-0330 HSS MC33.0x3.5 SET TAP ISO 529 Brooke M33 Set(3) 3.5 151 51 18 1 Box
You need to be logged in to see prices.
5501-03301 HSS MC33.0x3.5 TAPER TAP ISO 529 Brooke M33 Taper 3.5 151 51 18 1 Box
You need to be logged in to see prices.
5501-03302 HSS MC33.0x3.5 SECND TAP ISO 529 Brooke M33 Second 3.5 151 51 18 1 Box
You need to be logged in to see prices.
5501-03303 HSS MC33.0x3.5 BOT'G TAP ISO 529 Brooke M33 Bottom 3.5 151 51 18 1 Box
You need to be logged in to see prices.
5501-0360 HSS MC36.0x4.0 SET TAP ISO 529 Brooke M36 Set(3) 4 162 57 20 1 Box
You need to be logged in to see prices.
5501-03601 HSS MC36.0x4.0 TAPER TAP ISO 529 Brooke M36 Taper 4 162 57 20 1 Box
You need to be logged in to see prices.
5501-03602 HSS MC36.0x4.0 SECND TAP ISO 529 Brooke M36 Second 4 162 57 20 1 Box
You need to be logged in to see prices.
5501-03603 HSS MC36.0x4.0 BOT'G TAP ISO 529 Brooke M36 Bottom 4 162 57 20 1 Box
You need to be logged in to see prices.
5501-03901 HSS MC39.0x4.0 TAPER TAP ISO 529 Brooke M39 Taper 4 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-03902 HSS MC39.0x4.0 SECND TAP ISO 529 Brooke M39 Second 4 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-03903 HSS MC39.0x4.0 BOT'G TAP ISO 529 Brooke M39 Bottom 4 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-0420 HSS MC42.0x4.5 SET TAP ISO 529 Brooke M42 Set(3) 4.5 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-04201 HSS MC42.0x4.5 TAPER TAP ISO 529 Brooke M42 Taper 4.5 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-04202 HSS MC42.0x4.5 SECND TAP ISO 529 Brooke M42 Second 4.5 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-04203 HSS MC42.0x4.5 BOT'G TAP ISO 529 Brooke M42 Bottom 4.5 170 60 22.4 1 Box
You need to be logged in to see prices.
5501-0450 HSS MC45.0x4.5 SET TAP ISO 529 Brooke M45 Set(3) 4.5 187 67 25 1 Box
You need to be logged in to see prices.
5501-04501 HSS MC45.0x4.5 TAPER TAP ISO 529 Brooke M45 Taper 4.5 187 67 25 1 Box
You need to be logged in to see prices.
5501-04502 HSS MC45.0x4.5 SECND TAP ISO 529 Brooke M45 Second 4.5 187 67 25 1 Box
You need to be logged in to see prices.
5501-04503 HSS MC45.0x4.5 BOT'G TAP ISO 529 Brooke M45 Bottom 4.5 187 67 25 1 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
