Metric Coarse Spiral Point Machine Taps - Bright Finish
Metric Coarse Spiral Point Machine Taps - Bright Finish

Metric Coarse Spiral Point Machine Taps - Bright Finish

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Spiral point.
Surface Treatment
Bright
Application
For machine tapping of through holes in steel,stainless steels, cast irons and non-ferrous materials such as aluminium & brass.
Manufactured To
ISO 529
Material
HSSE-V

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5508-0030 BRGT Co5 SP.PT M3 ISO 529 TAP Brooke M3 0.5 48 11 2.5 1 Box
You need to be logged in to see prices.
5508-0040 BRGT Co5 SP.PT M4 ISO 529 TAP Brooke M4 0.7 53 13 3.15 1 Box
You need to be logged in to see prices.
5508-0050 BRGT Co5 SP.PT M5 ISO 529 TAP Brooke M5 0.8 58 16 4 1 Box
You need to be logged in to see prices.
5508-0060 BRGT Co5 SP.PT M6 ISO 529 TAP Brooke M6 1 66 19 5 1 Box
You need to be logged in to see prices.
5508-0080 BRGT Co5 SP.PT M8 ISO 529 TAP Brooke M8 1.25 72 22 6.3 1 Box
You need to be logged in to see prices.
5508-0100 BRGT Co5 SP.PT M10 ISO 529 TAP Brooke M10 1.5 80 24 8 1 Box
You need to be logged in to see prices.
5508-0120 BRGT Co5 SP.PT M12 ISO 529 TAP Brooke M12 1.75 89 29 7.1 1 Box
You need to be logged in to see prices.
5508-0140 BRGT Co5 SP.PT M14 ISO 529 TAP Brooke M14 2 95 30 9 1 Box
You need to be logged in to see prices.
5508-0160 BRGT Co5 SP.PT M16 ISO 529 TAP Brooke M16 2 102 32 10 1 Box
You need to be logged in to see prices.
5508-0200 BRGT Co5 SP.PT M20 ISO 529 TAP Brooke M20 2.5 112 37 11.2 1 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
