Metric Coarse Long Series Taps
Metric Coarse Long Series Taps

Metric Coarse Long Series Taps

Descriptions

Type of Thread
Metric ISO thread
Tap Tolerance
Class 2 for 6H fit
Flute Type
Straight flutes
Surface Treatment
Bright
Application
For hand tapping of through or blind holes in steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
ISO 529
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Type Pitch (mm) Overall Length (mm) Thread Length (mm) Square Section (mm) Pack Qty Packaged In/On Price
5516-00402 MC4.0 x 0.7 Second L/Series Tap HSS 75mm Overall M4 Second 0.7 73 13 3.15 1 Box
You need to be logged in to see prices.
5516-00502 MC5.0 x 0.8 Second L/Series Tap HSS 80mm Overall M5 Second 0.8 79 16 4 1 Box
You need to be logged in to see prices.
5516-00602 MC6.0 x 1.0 Second L/Series Tap HSS 90mm Overall M6 Second 1 89 19 5 1 Box
You need to be logged in to see prices.
5516-00802 MC8.0 x 1.25 Second L/Series Tap HSS 100mm Overall M8 Second 1.25 97 22 6.3 1 Box
You need to be logged in to see prices.
5516-01002 MC10.0 x 1.5 Second L/Series Tap HSS 110mm Overall M10 Second 1.5 108 24 8 1 Box
You need to be logged in to see prices.
5516-01202 MC12.0 x 1.75 Second L/Series Tap HSS 120mm Overall M12 Second 1.75 119 29 7.1 1 Box
You need to be logged in to see prices.
5516-01602 MC16.0 x 2.0 Second L/Series Tap HSS 140mm Overall M16 Second 2 137 32 10 1 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
