HSS-G TiN Coated Jobber Drill Bits
HSS-G TiN Coated Jobber Drill Bits

HSS-G TiN Coated Jobber Drill Bits

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
TiN coated increases tool life & preformance.
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics. Compared to traditional HSS jobber drill bits, speed can be increased by 40 -60% and feed by 10 -20% without reducing the life time of the drill bit significantly. TiN is also a poor conductor of heat, so the heat generated during the drilling process is diverted into the chips and coolant and less into the drill bit.
Manufactured To
Din 338
Material
HSS
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
5103-00050 KOMBAT JBR 0.50MM TIN COATED SPLIT POINT 0.50mm 6 22 10 Box
You need to be logged in to see prices.
5103-0010 KOMBAT JBR 1.0MM TIN COATED SPLIT POINT 1.0mm 12 34 10 Box
You need to be logged in to see prices.
5103-0013 KOMBAT JBR 1.3MM TIN COATED SPLIT POINT 1.3mm 16 38 10 Box
You need to be logged in to see prices.
5103-0015 KOMBAT JBR 1.5MM TIN COATED SPLIT POINT 1.5mm 18 40 10 Box
You need to be logged in to see prices.
5103-0016 KOMBAT JBR 1.6MM TIN COATED SPLIT POINT 1.6mm 20 43 10 Box
You need to be logged in to see prices.
5103-0020 KOMBAT JBR 2.0MM TIN COATED SPLIT POINT 2.0mm 24 49 10 Box
You need to be logged in to see prices.
5103-0021 KOMBAT JBR 2.1MM TIN COATED SPLIT POINT 2.1mm 24 49 10 Box
You need to be logged in to see prices.
5103-0022 KOMBAT JBR 2.2MM TIN COATED SPLIT POINT 2.2mm 27 53 10 Box
You need to be logged in to see prices.
5103-0023 KOMBAT JBR 2.3MM TIN COATED SPLIT POINT 2.3mm 27 53 10 Box
You need to be logged in to see prices.
5103-0024 KOMBAT JBR 2.4MM TIN COATED SPLIT POINT 2.4mm 30 57 10 Box
You need to be logged in to see prices.
5103-0025 KOMBAT JBR 2.5MM TIN COATED SPLIT POINT 2.5mm 30 57 10 Box
You need to be logged in to see prices.
5103-0026 KOMBAT JBR 2.6MM TIN COATED SPLIT POINT 2.6mm 30 57 10 Box
You need to be logged in to see prices.
5103-0027 KOMBAT JBR 2.7MM TIN COATED SPLIT POINT 2.7mm 33 61 10 Box
You need to be logged in to see prices.
5103-0028 KOMBAT JBR 2.80MM TIN COATED SPLIT POINT 2.8mm 33 61 10 Box
You need to be logged in to see prices.
5103-0029 KOMBAT JBR 2.9MM TIN COATED SPLIT POINT 2.9mm 33 61 10 Box
You need to be logged in to see prices.
5103-0030 KOMBAT JBR 3.0MM TIN COATED SPLIT POINT 3.0mm 33 61 10 Box
You need to be logged in to see prices.
5103-0031 KOMBAT JBR 3.1MM TIN COATED SPLIT POINT 3.1mm 35 65 10 Box
You need to be logged in to see prices.
5103-0032 KOMBAT JBR 3.2MM TIN COATED SPLIT POINT 3.2mm 35 65 10 Box
You need to be logged in to see prices.
5103-0033 KOMBAT JBR 3.3MM TIN COATED SPLIT POINT 3.3mm 35 65 10 Box
You need to be logged in to see prices.
5103-0034 KOMBAT JBR 3.4MM TIN COATED SPLIT POINT 3.4mm 39 70 10 Box
You need to be logged in to see prices.
5103-0035 KOMBAT JBR 3.5MM TIN COATED SPLIT POINT 3.5mm 39 70 10 Box
You need to be logged in to see prices.
5103-0036 KOMBAT JBR 3.6MM TIN COATED SPLIT POINT 3.6mm 39 70 10 Box
You need to be logged in to see prices.
5103-0037 KOMBAT JBR 3.7MM TIN COATED SPLIT POINT 3.7mm 39 70 10 Box
You need to be logged in to see prices.
5103-0038 KOMBAT JBR 3.8MM TIN COATED SPLIT POINT 3.8mm 43 75 10 Box
You need to be logged in to see prices.
5103-0039 KOMBAT JBR 3.9MM TIN COATED SPLIT POINT 3.9mm 43 75 10 Box
You need to be logged in to see prices.
5103-0040 KOMBAT JBR 4.0MM TIN COATED SPLIT POINT 4.0mm 43 75 10 Box
You need to be logged in to see prices.
5103-0041 KOMBAT JBR 4.1MM TIN COATED SPLIT POINT 4.1mm 43 75 10 Box
You need to be logged in to see prices.
5103-0042 KOMBAT JBR 4.2MM TIN COATED SPLIT POINT 4.2mm 43 75 10 Box
You need to be logged in to see prices.
5103-0043 KOMBAT JBR 4.3MM TIN COATED SPLIT POINT 4.3mm 47 80 10 Box
You need to be logged in to see prices.
5103-0045 KOMBAT JBR 4.5MM TIN COATED SPLIT POINT 4.5mm 47 80 10 Box
You need to be logged in to see prices.
5103-0046 KOMBAT JBR 4.6MM TIN COATED SPLIT POINT 4.6mm 47 80 10 Box
You need to be logged in to see prices.
5103-0047 KOMBAT JBR 4.7MM TIN COATED SPLIT POINT 4.7mm 47 80 10 Box
You need to be logged in to see prices.
5103-0048 KOMBAT JBR 4.8MM TIN COATED SPLIT POINT 4.8mm 52 86 10 Box
You need to be logged in to see prices.
5103-0049 KOMBAT JBR 4.9MM TIN COATED SPLIT POINT 4.9mm 52 86 10 Box
You need to be logged in to see prices.
5103-0050 KOMBAT JBR 5.0MM TIN COATED SPLIT POINT 5.0mm 52 86 10 Box
You need to be logged in to see prices.
5103-0051 KOMBAT JBR 5.1MM TIN COATED SPLIT POINT 5.1mm 52 86 10 Box
You need to be logged in to see prices.
5103-0052 KOMBAT JBR 5.2MM TIN COATED SPLIT POINT 5.2mm 52 86 10 Box
You need to be logged in to see prices.
5103-0053 KOMBAT JBR 5.3MM TIN COATED SPLIT POINT 5.3mm 52 86 10 Box
You need to be logged in to see prices.
5103-0054 KOMBAT JBR 5.4MM TIN COATED SPLIT POINT 5.4mm 57 93 10 Box
You need to be logged in to see prices.
5103-0055 KOMBAT JBR 5.5MM TIN COATED SPLIT POINT 5.5mm 57 93 10 Box
You need to be logged in to see prices.
5103-0056 KOMBAT JBR 5.6MM TIN COATED SPLIT POINT 5.6mm 57 93 10 Box
You need to be logged in to see prices.
5103-0057 KOMBAT JBR 5.7MM TIN COATED SPLIT POINT 5.7mm 57 93 10 Box
You need to be logged in to see prices.
5103-0058 KOMBAT JBR 5.8MM TIN COATED SPLIT POINT 5.8mm 57 93 10 Box
You need to be logged in to see prices.
5103-0059 KOMBAT JBR 5.9MM TIN COATED SPLIT POINT 5.9mm 57 93 10 Box
You need to be logged in to see prices.
5103-0060 KOMBAT JBR 6.0MM TIN COATED SPLIT POINT 6.0mm 57 93 10 Box
You need to be logged in to see prices.
5103-0061 KOMBAT JBR 6.1MM TIN COATED SPLIT POINT 6.1mm 63 101 10 Box
You need to be logged in to see prices.
5103-0062 KOMBAT JBR 6.2MM TIN COATED SPLIT POINT 6.2mm 63 101 10 Box
You need to be logged in to see prices.
5103-0063 KOMBAT JBR 6.3MM TIN COATED SPLIT POINT 6.3mm 63 101 10 Box
You need to be logged in to see prices.
5103-0064 KOMBAT JBR 6.4MM TIN COATED SPLIT POINT 6.4mm 63 101 10 Box
You need to be logged in to see prices.
5103-0065 KOMBAT JBR 6.5MM TIN COATED SPLIT POINT 6.5mm 63 101 10 Box
You need to be logged in to see prices.
5103-0066 KOMBAT JBR 6.6MM TIN COATED SPLIT POINT 6.6mm 63 101 10 Box
You need to be logged in to see prices.
5103-0067 KOMBAT JBR 6.7MM TIN COATED SPLIT POINT 6.7mm 63 101 10 Box
You need to be logged in to see prices.
5103-0068 KOMBAT JBR 6.8MM TIN COATED SPLIT POINT 6.8mm 69 101 10 Box
You need to be logged in to see prices.
5103-0069 KOMBAT JBR 6.9MM TIN COATED SPLIT POINT 6.9mm 69 101 10 Box
You need to be logged in to see prices.
5103-0070 KOMBAT JBR 7.0MM TIN COATED SPLIT POINT 7.0mm 69 101 10 Box
You need to be logged in to see prices.
5103-0071 KOMBAT JBR 7.1MM TIN COATED SPLIT POINT 7.1mm 69 101 10 Box
You need to be logged in to see prices.
5103-0072 KOMBAT JBR 7.2MM TIN COATED SPLIT POINT 7.2mm 69 109 10 Box
You need to be logged in to see prices.
5103-0073 KOMBAT JBR 7.3MM TIN COATED SPLIT POINT 7.3mm 69 109 10 Box
You need to be logged in to see prices.
5103-0075 KOMBAT JBR 7.5MM TIN COATED SPLIT POINT 7.5mm 69 109 10 Box
You need to be logged in to see prices.
5103-0076 KOMBAT JBR 7.6MM TIN COATED SPLIT POINT 7.6mm 75 117 10 Box
You need to be logged in to see prices.
5103-0078 KOMBAT JBR 7.8MM TIN COATED SPLIT POINT 7.8mm 75 117 10 Box
You need to be logged in to see prices.
5103-0080 KOMBAT JBR 8.0MM TIN COATED SPLIT POINT 8.0mm 75 117 10 Box
You need to be logged in to see prices.
5103-0082 KOMBAT JBR 8.2MM TIN COATED SPLIT POINT 8.2mm 75 117 10 Box
You need to be logged in to see prices.
5103-0083 KOMBAT JBR 8.3MM TIN COATED SPLIT POINT 8.3mm 75 117 10 Box
You need to be logged in to see prices.
5103-0084 KOMBAT JBR 8.4MM TIN COATED SPLIT POINT 8.4mm 75 117 10 Box
You need to be logged in to see prices.
5103-0085 KOMBAT JBR 8.5MM TIN COATED SPLIT POINT 8.5mm 75 117 10 Box
You need to be logged in to see prices.
5103-0086 KOMBAT JBR 8.6MM TIN COATED SPLIT POINT 8.6mm 81 125 10 Box
You need to be logged in to see prices.
5103-0087 KOMBAT JBR 8.7MM TIN COATED SPLIT POINT 8.7mm 81 125 10 Box
You need to be logged in to see prices.
5103-0088 KOMBAT JBR 8.8MM TIN COATED SPLIT POINT 8.8mm 81 125 10 Box
You need to be logged in to see prices.
5103-0090 KOMBAT JBR 9.0MM TIN COATED SPLIT POINT 9.0mm 81 125 10 Box
You need to be logged in to see prices.
5103-0091 KOMBAT JBR 9.1MM TIN COATED SPLIT POINT 9.1mm 81 125 10 Box
You need to be logged in to see prices.
5103-0093 KOMBAT JBR 9.3MM TIN COATED SPLIT POINT 9.3mm 81 125 10 Box
You need to be logged in to see prices.
5103-0094 KOMBAT JBR 9.4MM TIN COATED SPLIT POINT 9.4mm 81 125 10 Box
You need to be logged in to see prices.
5103-0095 KOMBAT JBR 9.5MM TIN COATED SPLIT POINT 9.5mm 81 125 10 Box
You need to be logged in to see prices.
5103-0096 KOMBAT JBR 9.6MM TIN COATED SPLIT POINT 9.6mm 87 133 10 Box
You need to be logged in to see prices.
5103-0098 KOMBAT JBR 9.8MM TIN COATED SPLIT POINT 9.8mm 87 133 10 Box
You need to be logged in to see prices.
5103-0100 KOMBAT JBR 10.0MM TIN COATED SPLIT POINT 10.0mm 87 133 10 Box
You need to be logged in to see prices.
5103-0101 KOMBAT JBR 10.1MM TIN COATED SPLIT POINT 10.1mm 87 133 5 Box
You need to be logged in to see prices.
5103-0102 KOMBAT JBR 10.2MM TIN COATED SPLIT POINT 10.2mm 87 133 5 Box
You need to be logged in to see prices.
5103-0103 KOMBAT JBR 10.3MM TIN COATED SPLIT POINT 10.3mm 87 133 5 Box
You need to be logged in to see prices.
5103-0104 KOMBAT JBR 10.4MM TIN COATED SPLIT POINT 10.4mm 87 133 5 Box
You need to be logged in to see prices.
5103-0105 KOMBAT JBR 10.5MM TIN COATED SPLIT POINT 10.5mm 87 133 5 Box
You need to be logged in to see prices.
5103-0106 KOMBAT JBR 10.6MM TIN COATED SPLIT POINT 10.6mm 87 133 5 Box
You need to be logged in to see prices.
5103-0108 KOMBAT JBR 10.8MM TIN COATED SPLIT POINT 10.8mm 94 142 5 Box
You need to be logged in to see prices.
5103-0109 KOMBAT JBR 10.9MM TIN COATED SPLIT POINT 10.9mm 94 142 5 Box
You need to be logged in to see prices.
5103-0110 KOMBAT JBR 11.0MM TIN COATED SPLIT POINT 11.0mm 94 142 5 Box
You need to be logged in to see prices.
5103-0111 KOMBAT JBR 11.1MM TIN COATED SPLIT POINT 11.1mm 94 142 5 Box
You need to be logged in to see prices.
5103-0112 KOMBAT JBR 11.2MM TIN COATED SPLIT POINT 11.2mm 94 142 5 Box
You need to be logged in to see prices.
5103-0114 KOMBAT JBR 11.4MM TIN COATED SPLIT POINT 11.4mm 94 142 5 Box
You need to be logged in to see prices.
5103-0115 KOMBAT JBR 11.5MM TIN COATED SPLIT POINT 11.5mm 94 142 5 Box
You need to be logged in to see prices.
5103-0118 KOMBAT JBR 11.8MM TIN COATED SPLIT POINT 11.8mm 94 142 5 Box
You need to be logged in to see prices.
5103-0120 KOMBAT JBR 12.0MM TIN COATED SPLIT POINT 12.0mm 101 151 5 Box
You need to be logged in to see prices.
5103-0121 KOMBAT JBR 12.1MM TIN COATED SPLIT POINT 12.1mm 101 151 5 Box
You need to be logged in to see prices.
5103-0122 KOMBAT JBR 12.2MM TIN COATED SPLIT POINT 12.2mm 101 151 5 Box
You need to be logged in to see prices.
5103-0125 KOMBAT JBR 12.5MM TIN COATED SPLIT POINT 12.5mm 101 151 5 Box
You need to be logged in to see prices.
5103-0127 KOMBAT JBR 12.7MM TIN COATED SPLIT POINT 12.7mm 101 151 5 Box
You need to be logged in to see prices.
5103-0128 KOMBAT JBR 12.8MM TIN COATED SPLIT POINT 12.8mm 101 151 5 Box
You need to be logged in to see prices.
5103-0130 KOMBAT JBR 13.0MM TIN COATED SPLIT POINT 13.0mm 101 151 5 Box
You need to be logged in to see prices.
5103-0135 KOMBAT JBR 13.5MM TIN COATED SPLIT POINT 13.5mm 108 160 1 Box
You need to be logged in to see prices.
5103-0140 KOMBAT JBR 14.0MM TIN COATED SPLIT POINT 14.0mm 108 160 1 Box
You need to be logged in to see prices.
5103-0145 KOMBAT JBR 14.5MM TIN COATED SPLIT POINT 14.5mm 114 169 1 Box
You need to be logged in to see prices.
5103-0150 KOMBAT JBR 15.0MM TIN COATED SPLIT POINT 15.0mm 114 169 1 Box
You need to be logged in to see prices.
5103-0160 KOMBAT JBR 16.0MM TIN COATED SPLIT POINT 16.0mm 120 178 1 Box
You need to be logged in to see prices.
5103-1005 KOMBAT JBR 5/64 TIN COATED SPLIT POINT 5/64" 24 49 10 Box
You need to be logged in to see prices.
5103-1006 KOMBAT JBR 3/32 TIN COATED SPLIT POINT 3/32" 30 57 10 Box
You need to be logged in to see prices.
5103-1007 KOMBAT JBR 7/64 TIN COATED SPLIT POINT 7/64" 33 61 10 Box
You need to be logged in to see prices.
5103-1008 KOMBAT JBR 1/8 TIN COATED SPLIT POINT 1/8" 36 65 10 Box
You need to be logged in to see prices.
5103-1009 KOMBAT JBR 9/64 TIN COATED SPLIT POINT 9/64" 39 70 10 Box
You need to be logged in to see prices.
5103-1010 KOMBAT JBR 5/32 TIN COATED SPLIT POINT 5/32" 43 75 10 Box
You need to be logged in to see prices.
5103-1011 KOMBAT JBR 11/64 TIN COATED SPLIT POINT 11/64" 47 80 10 Box
You need to be logged in to see prices.
5103-1012 KOMBAT JBR 3/16 TIN COATED SPLIT POINT 3/16" 53 86 10 Box
You need to be logged in to see prices.
5103-1013 KOMBAT JBR 13/64 TIN COATED SPLIT POINT 13/64" 53 86 10 Box
You need to be logged in to see prices.
5103-1014 KOMBAT JBR 7/32 TIN COATED SPLIT POINT 7/32" 57 93 10 Box
You need to be logged in to see prices.
5103-1016 KOMBAT JBR 1/4 TIN COATED SPLIT POINT 1/4" 63 101 10 Box
You need to be logged in to see prices.
5103-1017 KOMBAT JBR 17/64 TIN COATED SPLIT POINT 17/64" 69 109 10 Box
You need to be logged in to see prices.
5103-1032 KOMBAT JBR 1/2 TIN COATED SPLIT POINT 1/2" 101 151 5 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
