HSS-G Long Series Drill Bits Boxed
HSS-G Long Series Drill Bits Boxed

HSS-G Long Series Drill Bits Boxed

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
Blue oxide
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics.
Manufactured To
Din 340
Material
HSS
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C106-0015 1.50mm Long Series Ground Flute 1.50mm 45 70 10 Box
You need to be logged in to see prices.
C106-0020 2.00mm Long Series Ground Flute 2.00mm 56 85 10 Box
You need to be logged in to see prices.
C106-0025 2.50mm Long Series Ground Flute 2.50mm 62 95 10 Box
You need to be logged in to see prices.
C106-0030 3.00mm Long Series Ground Flute 3.00mm 66 100 10 Box
You need to be logged in to see prices.
C106-0035 3.50mm Long Series Ground Flute 3.50mm 73 112 10 Box
You need to be logged in to see prices.
C106-0040 4.00mm Long Series Ground Flute 4.00mm 78 119 10 Box
You need to be logged in to see prices.
C106-0045 4.50mm Long Series Ground Flute 4.50mm 82 126 10 Box
You need to be logged in to see prices.
C106-0050 5.00mm Long Series Ground Flute 5.00mm 87 132 10 Box
You need to be logged in to see prices.
C106-0055 5.50mm Long Series Ground Flute 5.50mm 91 139 10 Box
You need to be logged in to see prices.
C106-0060 6.00mm Long Series Ground Flute 6.00mm 91 139 10 Box
You need to be logged in to see prices.
C106-0065 6.50mm Long Series Ground Flute 6.50mm 97 148 10 Box
You need to be logged in to see prices.
C106-0070 7.00mm Long Series Ground Flute 7.00mm 102 156 10 Box
You need to be logged in to see prices.
C106-0075 7.50mm Long Series Ground Flute 7.50mm 102 156 10 Box
You need to be logged in to see prices.
C106-0080 8.00mm Long Series Ground Flute 8.00mm 109 165 10 Box
You need to be logged in to see prices.
C106-0085 8.50mm Long Series Ground Flute 8.50mm 109 165 10 Box
You need to be logged in to see prices.
C106-0090 9.00mm Long Series Ground Flute 9.00mm 115 175 10 Box
You need to be logged in to see prices.
C106-0095 9.50mm Long Series Ground Flute 9.50mm 115 175 10 Box
You need to be logged in to see prices.
C106-0100 10.00mm Long Series Ground Flute 10.00mm 121 184 10 Box
You need to be logged in to see prices.
C106-0105 10.50mm Long Series Ground Flute 10.50mm 121 184 5 Box
You need to be logged in to see prices.
C106-0110 11.00mm Long Series Ground Flute 11.00mm 128 195 5 Box
You need to be logged in to see prices.
C106-0115 11.50mm Long Series Ground Flute 11.50mm 128 195 5 Box
You need to be logged in to see prices.
C106-0120 12.00mm Long Series Ground Flute 12.00mm 134 205 5 Box
You need to be logged in to see prices.
C106-0125 12.50mm Long Series Ground Flute 12.50mm 134 205 5 Box
You need to be logged in to see prices.
C106-0130 13.00mm Long Series Ground Flute 13.00mm 134 205 5 Box
You need to be logged in to see prices.
C106-0140 14.00mm Long Series Ground Flute 14.00mm 140 214 1 Box
You need to be logged in to see prices.
You need to be logged in to see prices.
