HSS-G Jobber Drill Bits

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
Blue oxide
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics.
Manufactured To
Din 338
Material
HSS
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
5101-00085 HSS PS JOBBER 0.85 Ground Flt DIN 338 DRILLS 0.85mm 10 30 10 Box
5101-0010 HSS PS JOBBER 1.00 Ground Flt DIN 338 DRILLS 1.0mm 12 34 10 Box
5101-0013 HSS PS JOBBER 1.30 Ground Flt DIN 338 DRILLS 1.3mm 16 38 10 Box
5101-0014 HSS PS JOBBER 1.40 Ground Flt DIN 338 DRILLS 1.4mm 18 40 10 Box
5101-0015 HSS PS JOBBER 1.50 Ground Fl DIN 338 DRILLS 1.5mm 18 40 10 Box
5101-0016 HSS PS JOBBER 1.60 Ground Flt DIN 338 DRILLS 1.6mm 20 43 10 Box
5101-0017 HSS PS JOBBER 1.70 Ground Flt DIN 338 DRILLS 1.7mm 20 43 10 Box
5101-00175 HSS PS JOBBER 1.75 Ground Flt DIN 338 DRILLS 1.75mm 22 46 10 Box
5101-0018 HSS PS JOBBER 1.80 Ground Flt DIN 338 DRILLS 1.8mm 22 46 10 Box
5101-0019 HSS PS JOBBER 1.90 Ground Flt DIN 338 DRILLS 1.9mm 22 46 10 Box
5101-0020 HSS PS JOBBER 2.00 Ground Flt DIN 338 DRILLS 2.0mm 24 49 10 Box
5101-0021 HSS PS JOBBER 2.10 Ground Flt DIN 338 DRILLS 2.1mm 24 49 10 Box
5101-0022 HSS PS JOBBER 2.20 Ground Flt DIN 338 DRILLS 2.2mm 27 53 10 Box
5101-0023 HSS PS JOBBER 2.30 Ground Flt DIN 338 DRILLS 2.3mm 27 53 10 Box
5101-00235 HSS PS JOBBER 2.35 Ground Flt DIN 338 DRILLS 2.35mm 27 53 10 Box
5101-0024 HSS PS JOBBER 2.40 Ground Flt DIN 338 DRILLS 2.4mm 30 57 10 Box
5101-00245 HSS PS JOBBER 2.45 Ground Flt DIN 338 DRILLS 2.45mm 30 57 10 Box
5101-0025 HSS PS JOBBER 2.50 Ground Flt DIN 338 DRILLS 2.5mm 30 57 10 Box
5101-0026 HSS PS JOBBER 2.60 Ground Flt DIN 338 DRILLS 2.6mm 30 57 10 Box
5101-0027 HSS PS JOBBER 2.70 Ground Flt DIN 338 DRILLS 2.7mm 33 61 10 Box
5101-0028 HSS PS JOBBER 2.80 Ground Flt DIN 338 DRILLS 2.8mm 33 61 10 Box
5101-0029 HSS PS JOBBER 2.90 Ground Flt DIN 338 DRILLS 2.9mm 33 61 10 Box
5101-0030 HSS PS JOBBER 3.00 Ground Flt DIN 338 DRILLS 3.0mm 33 61 10 Box
5101-0031 HSS PS JOBBER 3.10 Ground Flt DIN 338 DRILLS 3.1mm 36 65 10 Box
5101-0032 HSS PS JOBBER 3.20 Ground Flt DIN 338 DRILLS 3.2mm 36 65 10 Box
5101-00325 HSS PS JOBBER 3.25 Ground Flt DIN 338 DRILLS 3.25mm 36 65 10 Box
5101-0033 HSS PS JOBBER 3.30 Ground Flt DIN 338 DRILLS 3.3mm 36 65 10 Box
5101-0034 HSS PS JOBBER 3.40 Ground Flt DIN 338 DRILLS 3.4mm 39 70 10 Box
5101-0035 HSS PS JOBBER 3.50 Ground Flt DIN 338 DRILLS 3.5mm 39 70 10 Box
5101-0036 HSS PS JOBBER 3.60 Ground Flt DIN 338 DRILLS 3.6mm 39 70 10 Box
5101-0037 HSS PS JOBBER 3.70 Ground Flt DIN 338 DRILLS 3.7mm 39 70 10 Box
5101-0038 HSS PS JOBBER 3.80 Ground Flt DIN 338 DRILLS 3.8mm 43 75 10 Box
5101-0039 HSS PS JOBBER 3.90 Ground Flt DIN 338 DRILLS 3.9mm 43 75 10 Box
5101-0040 HSS PS JOBBER 4.00 Ground Flt DIN 338 DRILLS 4.0mm 43 75 10 Box
5101-0041 HSS PS JOBBER 4.10 Ground Flt DIN 338 DRILLS 4.1mm 43 75 10 Box
5101-0042 HSS PS JOBBER 4.20 Ground Flt DIN 338 DRILLS 4.2mm 43 75 10 Box
5101-00425 HSS PS JOBBER 4.25 Ground Flt DIN 338 DRILLS 4.25mm 43 75 10 Box
5101-0043 HSS PS JOBBER 4.30 Ground Flt DIN 338 DRILLS 4.3mm 47 80 10 Box
5101-0044 HSS PS JOBBER 4.40 Ground Flt DIN 338 DRILLS 4.4mm 47 80 10 Box
5101-0045 HSS PS JOBBER 4.50 Ground Flt DIN 338 DRILLS 4.5mm 47 80 10 Box
5101-0046 HSS PS JOBBER 4.60 Ground Flt DIN 338 DRILLS 4.6mm 47 80 10 Box
5101-0047 HSS PS JOBBER 4.70 Ground Flt DIN 338 DRILLS 4.7mm 47 80 10 Box
5101-00475 HSS PS JOBBER 4.75 Ground Flt DIN 338 DRILLS 4.75mm 47 80 10 Box
5101-0048 HSS PS JOBBER 4.80 Ground Flt DIN 338 DRILLS 4.8mm 52 86 10 Box
5101-0049 HSS PS JOBBER 4.90 Ground Flt DIN 338 DRILLS 4.9mm 52 86 10 Box
5101-0050 HSS PS JOBBER 5.00 Ground Flt DIN 338 DRILLS 5.0mm 52 86 10 Box
5101-0051 HSS PS JOBBER 5.10 Ground Flt DIN 338 DRILLS 5.1mm 52 86 10 Box
5101-0052 HSS PS JOBBER 5.20 Ground Flt DIN 338 DRILLS 5.2mm 52 86 10 Box
5101-00525 HSS PS JOBBER 5.25 Ground Flt DIN 338 DRILLS 5.25mm 52 86 10 Box
5101-0053 HSS PS JOBBER 5.30 Ground Flt DIN 338 DRILLS 5.3mm 52 86 10 Box
5101-0054 HSS PS JOBBER 5.40 Ground Flt DIN 338 DRILLS 5.4mm 57 93 10 Box
5101-0055 HSS PS JOBBER 5.50 Ground Flt DIN 338 DRILLS 5.5mm 57 93 10 Box
5101-0056 HSS PS JOBBER 5.60 Ground Flt DIN 338 DRILLS 5.6mm 57 93 10 Box
5101-0057 HSS PS JOBBER 5.70 Ground Flt DIN 338 DRILLS 5.7mm 57 93 10 Box
5101-00575 HSS PS JOBBER 5.75 Ground Flt DIN 338 DRILLS 5.75mm 57 93 10 Box
5101-0058 HSS PS JOBBER 5.80 Ground Flt DIN 338 DRILLS 5.8mm 57 93 10 Box
5101-0059 HSS PS JOBBER 5.90 Ground Flt DIN 338 DRILLS 5.9mm 57 93 10 Box
5101-0060 HSS PS JOBBER 6.00 Ground Flt DIN 338 DRILLS 6.0mm 57 93 10 Box
5101-0061 HSS PS JOBBER 6.10 Ground Flt DIN 338 DRILLS 6.1mm 63 101 10 Box
5101-0062 HSS PS JOBBER 6.20 Ground Flt DIN 338 DRILLS 6.2mm 63 101 10 Box
5101-00625 HSS PS JOBBER 6.25 Ground Flt DIN 338 DRILLS 6.25mm 63 101 10 Box
5101-0063 HSS PS JOBBER 6.30 Ground Flt DIN 338 DRILLS 6.3mm 63 101 10 Box
5101-0064 HSS PS JOBBER 6.40 Ground Flt DIN 338 DRILLS 6.4mm 63 101 10 Box
5101-0065 HSS PS JOBBER 6.50 Ground Flt DIN 338 DRILLS 6.5mm 63 101 10 Box
5101-0066 HSS PS JOBBER 6.60 Ground Flt DIN 338 DRILLS 6.6mm 63 101 10 Box
5101-0067 HSS PS JOBBER 6.70 Ground Flt DIN 338 DRILLS 6.7mm 63 101 10 Box
5101-00675 HSS PS JOBBER 6.75 Ground Flt DIN 338 DRILLS 6.75mm 63 101 10 Box
5101-0068 HSS PS JOBBER 6.80 Ground Flt DIN 338 DRILLS 6.8mm 63 101 10 Box
5101-0069 HSS PS JOBBER 6.90 Ground Flt DIN 338 DRILLS 6.9mm 63 101 10 Box
5101-0070 HSS PS JOBBER 7.00 Ground Flt DIN 338 DRILLS 7.0mm 63 101 10 Box
5101-0071 HSS PS JOBBER 7.10 Ground Flt DIN 338 DRILLS 7.1mm 69 109 10 Box
5101-0072 HSS PS JOBBER 7.20 Ground Flt DIN 338 DRILLS 7.2mm 69 109 10 Box
5101-0073 HSS PS JOBBER 7.30 Ground Flt DIN 338 DRILLS 7.3mm 69 109 10 Box
5101-0074 HSS PS JOBBER 7.40 Ground Flt DIN 338 DRILLS 7.4mm 69 109 10 Box
5101-0075 HSS PS JOBBER 7.50 Ground Flt DIN 338 DRILLS 7.5mm 69 109 10 Box
5101-0076 HSS PS JOBBER 7.60 Ground Flt DIN 338 DRILLS 7.6mm 75 117 10 Box
5101-00775 HSS PS JOBBER 7.75 Ground Flt DIN 338 DRILLS 7.75mm 75 117 10 Box
5101-0078 HSS PS JOBBER 7.80 Ground Flt DIN 338 DRILLS 7.8mm 75 117 10 Box
5101-0079 HSS PS JOBBER 7.90 Ground Flt DIN 338 DRILLS 7.9mm 75 117 10 Box
5101-0080 HSS PS JOBBER 8.00 Ground Flt DIN 338 DRILLS 8.0mm 75 117 10 Box
5101-0081 HSS PS JOBBER 8.10 Ground Flt DIN 338 DRILLS 8.1mm 75 117 10 Box
5101-0082 HSS PS JOBBER 8.20 Ground Flt DIN 338 DRILLS 8.2mm 75 117 10 Box
5101-0083 HSS PS JOBBER 8.30 Ground Flt DIN 338 DRILLS 8.3mm 75 117 10 Box
5101-0084 HSS PS JOBBER 8.40 Ground Flt DIN 338 DRILLS 8.4mm 75 117 10 Box
5101-0085 HSS PS JOBBER 8.50 Ground Flt DIN 338 DRILLS 8.5mm 75 117 10 Box
5101-0086 HSS PS JOBBER 8.60 Ground Flt DIN 338 DRILLS 8.6mm 81 125 10 Box
5101-0087 HSS PS JOBBER 8.70 Ground Flt DIN 338 DRILLS 8.7mm 81 125 10 Box
5101-0088 HSS PS JOBBER 8.80 Ground Flt DIN 338 DRILLS 8.8mm 81 125 10 Box
5101-0089 HSS PS JOBBER 8.90 Ground Flt DIN 338 DRILLS 8.9mm 81 125 10 Box
5101-0090 HSS PS JOBBER 9.00 Ground Flt DIN 338 DRILLS 9.0mm 81 125 10 Box
5101-0091 HSS PS JOBBER 9.10 Ground Flt DIN 338 DRILLS 9.1mm 81 125 10 Box
5101-0092 HSS PS JOBBER 9.20 Ground Flt DIN 338 DRILLS 9.2mm 81 125 10 Box
5101-0093 HSS PS JOBBER 9.30 Ground Flt DIN 338 DRILLS 9.3mm 81 125 10 Box
5101-0094 HSS PS JOBBER 9.40 Ground Flt DIN 338 DRILLS 9.4mm 81 125 10 Box
5101-0095 HSS PS JOBBER 9.50 Ground Flt DIN 338 DRILLS 9.5mm 81 125 10 Box
5101-0096 HSS PS JOBBER 9.60 Ground Flt DIN 338 DRILLS 9.6mm 87 133 10 Box
5101-0097 HSS PS JOBBER 9.70 Ground Flt DIN 338 DRILLS 9.7mm 87 133 10 Box
5101-0098 HSS PS JOBBER 9.80 Ground Flt DIN 338 DRILLS 9.8mm 87 133 10 Box
5101-0100 HSS PS JOBBER 10.00 Ground Flt DIN 338 DRILLS 10.0mm 87 133 10 Box
5101-0101 HSS PS JOBBER 10.10 Ground Flt DIN 338 DRILLS 10.1mm 87 133 5 Box
5101-0102 HSS PS JOBBER 10.20 Ground Flt DIN 338 DRILLS 10.2mm 87 133 5 Box
5101-0103 HSS PS JOBBER 10.30 Ground Flt DIN 338 DRILLS 10.3mm 87 133 5 Box
5101-0104 HSS PS JOBBER 10.40 Ground Flt DIN 338 DRILLS 10.4mm 94 142 5 Box
5101-0105 HSS PS JOBBER 10.50 Ground Flt DIN 338 DRILLS 10.5mm 94 142 5 Box
5101-0106 HSS PS JOBBER 10.60 Ground Flt DIN 338 DRILLS 10.6mm 94 142 5 Box
5101-0107 HSS PS JOBBER 10.70 Ground Flt DIN 338 DRILLS 10.7mm 94 142 5 Box
5101-0108 HSS PS JOBBER 10.80 Ground Flt DIN 338 DRILLS 10.8mm 94 142 5 Box
5101-0109 HSS PS JOBBER 10.90 Ground Flt DIN 338 DRILLS 10.9mm 94 142 5 Box
5101-0110 HSS PS JOBBER 11.00 Ground Flt DIN 338 DRILLS 11.0mm 94 142 5 Box
5101-0111 HSS PS JOBBER 11.10 Ground Flt DIN 338 DRILLS 11.1mm 94 142 5 Box
5101-0112 HSS PS JOBBER 11.20 Ground Flt DIN 338 DRILLS 11.2mm 94 142 5 Box
5101-0113 HSS PS JOBBER 11.30 Ground Flt DIN 338 DRILLS 11.3mm 94 142 5 Box
5101-0115 HSS PS JOBBER 11.50 Ground Flt DIN 338 DRILLS 11.5mm 94 142 5 Box
5101-0117 HSS PS JOBBER 11.70 Ground Flt DIN 338 DRILLS 11.7mm 94 142 5 Box
5101-0118 HSS PS JOBBER 11.80 Ground Flt DIN 338 DRILLS 11.8mm 94 142 5 Box
5101-0119 HSS PS JOBBER 11.90 Ground Flt DIN 338 DRILLS 11.9mm 101 151 5 Box
5101-0120 HSS PS JOBBER 12.00 Ground Flt DIN 338 DRILLS 12.0mm 101 151 5 Box
5101-0122 HSS PS JOBBER 12.20 Ground Flt DIN 338 DRILLS 12.2mm 101 151 5 Box
5101-0124 HSS PS JOBBER 12.40 Ground Flt DIN 338 DRILLS 12.4mm 101 151 5 Box
5101-0125 HSS PS JOBBER 12.50 Ground Flt DIN 338 DRILLS 12.5mm 101 151 5 Box
5101-0127 HSS PS JOBBER 12.70 Ground Flt DIN 338 DRILLS 12.7mm 101 151 5 Box
5101-0130 HSS PS JOBBER 13.00 Ground Flt DIN 338 DRILLS 13.0mm 101 151 5 Box
5101-0135 HSS PS JOBBER 13.50 Ground Flt DIN 338 DRILLS 13.5mm 108 160 1 Box
5101-0140 HSS PS JOBBER 14.00 Ground Flt DIN 338 DRILLS 14.0mm 108 160 1 Box
5101-0145 HSS PS JOBBER 14.50 Ground Flt DIN 338 DRILLS 14.5mm 114 169 1 Box
5101-0150 HSS PS JOBBER 15.00 DIN 338 DRILLS 15.0mm 114 169 1 Box
5101-0155 HSS PS JOBBER 15.50 DIN 338 DRILLS 15.5mm 120 178 1 Box
5101-0160 HSS PS JOBBER 16.00 DIN 338 DRILLS 16.0mm 120 178 1 Box
5101-0165 HSS PS JOBBER 16.50 DIN 338 DRILLS 16.5mm 125 184 1 Box
5101-0170 HSS PS JOBBER 17.00 DIN 338 DRILLS 17.0mm 125 184 1 Box
5101-0175 HSS PS JOBBER 17.50 DIN 338 DRILLS 17.5mm 130 191 1 Box
5101-0180 HSS PS JOBBER 18.00 DIN 338 DRILLS 18.0mm 130 191 1 Box
5101-0185 HSS PS JOBBER 18.50 DIN 338 DRILLS 18.5mm 135 198 1 Box
5101-0190 HSS PS JOBBER 19.00 DIN 338 DRILLS 19.0mm 135 198 1 Box
5101-0195 HSS PS JOBBER 19.50 DIN 338 DRILLS 19.5mm 140 205 1 Box
5101-0200 HSS PS JOBBER 20.00 DIN 338 DRILLS 20.0mm 140 205 1 Box
5101-1002 HSS PS JOBBER 1/32 DIN 338 DRILLS 1/32" 10 30 10 Box
5101-1003 HSS PS JOBBER 3/64 DIN 338 DRILLS 3/64" 16 38 10 Box
5101-1004 HSS PS JOBBER 1/16 DIN 338 DRILLS 1/16" 20 43 10 Box
5101-1005 HSS PS JOBBER 5/64 DIN 338 DRILLS 5/64" 24 49 10 Box
5101-1006 HSS PS JOBBER 3/32 DIN 338 DRILLS 3/32" 30 57 10 Box
5101-1007 HSS PS JOBBER 7/64 DIN 338 DRILLS 7/64" 33 61 10 Box
5101-1008 HSS PS JOBBER 1/8 DIN 338 DRILLS 1/8" 35 65 10 Box
5101-1009 HSS PS JOBBER 9/64 DIN 338 DRILLS 9/64" 39 70 10 Box
5101-1010 HSS PS JOBBER 5/32 DIN 338 DRILLS 5/32" 43 75 10 Box
5101-1011 HSS PS JOBBER 11/64 DIN 338 DRILLS 11/64" 47 80 10 Box
5101-1012 HSS PS JOBBER 3/16 DIN 338 DRILLS 3/16" 52 86 10 Box
5101-1013 HSS PS JOBBER 13/64 DIN 338 DRILLS 13/64" 52 86 10 Box
5101-1014 HSS PS JOBBER 7/32 DIN 338 DRILLS 7/32" 57 93 10 Box
5101-1015 HSS PS JOBBER 15/64 DIN 338 DRILLS 15/64" 57 93 10 Box
5101-1016 HSS PS JOBBER 1/4 DIN 338 DRILLS 1/4" 63 101 10 Box
5101-1017 HSS PS JOBBER 17/64 DIN 338 DRILLS 17/64" 69 109 10 Box
5101-1018 HSS PS JOBBER 9/32 DIN 338 DRILLS 9/32" 69 109 10 Box
5101-1019 HSS PS JOBBER 19/64 DIN 338 DRILLS 19/64" 75 117 10 Box
5101-1020 HSS PS JOBBER 5/16 DIN 338 DRILLS 5/16" 75 117 10 Box
5101-1021 HSS PS JOBBER 21/64 DIN 338 DRILLS 21/64" 75 117 10 Box
5101-1022 HSS PS JOBBER 11/32 DIN 338 DRILLS 11/32" 81 125 10 Box
5101-1023 HSS PS JOBBER 23/64 DIN 338 DRILLS 23/64" 81 125 10 Box
5101-1024 HSS PS JOBBER 3/8 DIN 338 DRILLS 3/8" 87 133 10 Box
5101-1025 HSS PS JOBBER 25/64 DIN 338 DRILLS 25/64" 87 133 10 Box
5101-1026 HSS PS JOBBER 13/32 DIN 338 DRILLS 13/32" 87 133 5 Box
5101-1028 HSS PS JOBBER 7/16 DIN 338 DRILLS 7/16" 94 142 5 Box
5101-1029 HSS PS JOBBER 29/64 DIN 338 DRILLS 29/64" 94 142 5 Box
5101-1030 HSS PS JOBBER 15/32 DIN 338 DRILLS 15/32" 101 151 5 Box
5101-1031 HSS PS JOBBER 31/64 DIN 338 DRILLS 31/64" 101 151 5 Box
5101-1032 HSS PS JOBBER 1/2 DIN 338 DRILLS 1/2" 101 151 5 Box
5101-1034 HSS PS JOBBER 17/32 DIN 338 DRILLS 17/32" 108 160 1 Box
5101-1036 HSS PS JOBBER 9/16 DIN 338 DRILLS 9/16" 114 169 1 Box
5101-1040 HSS PS JOBBER 5/8 DIN 338 DRILLS 5/8" 120 178 1 Box
You need to be logged in to see prices.
