HSS-Co5 Cobalt Jobber Drill Bits Boxed
HSS-Co5 Cobalt Jobber Drill Bits Boxed

HSS-Co5 Cobalt Jobber Drill Bits Boxed

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
Straw Finish
Application
Drills in steel, high tensile steel up to 1000N/mm2, stainless steel V2A/V4A, cast steel, cast iron,non-ferrous metals and hard plastics
Manufactured To
Din 338
Material
HSS-Co5
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C107-0010 CJM01.0 1.0 mm Jobber Drills Cobalt 1.0 mm 12 34 10 Box
You need to be logged in to see prices.
C107-0015 CJM01.5 1.5 mm Jobber Drills Cobalt 1.5 mm 18 40 10 Box
You need to be logged in to see prices.
C107-0020 CJM02.0 2.0 mm Jobber Drills Cobalt 2.0 mm 24 49 10 Box
You need to be logged in to see prices.
C107-0025 CJM02.5 2.5 mm Jobber Drills Cobalt 2.5 mm 30 57 10 Box
You need to be logged in to see prices.
C107-0030 CJM03.0 3.0 mm Jobber Drills Cobalt 3.0 mm 33 61 10 Box
You need to be logged in to see prices.
C107-0032 CJM03.2 3.2 mm Jobber Drills Cobalt 3.2 mm 36 65 10 Box
You need to be logged in to see prices.
C107-0033 CJM03.3 3.3 mm Jobber Drills Cobalt 3.3mm 36 65 10 Box
You need to be logged in to see prices.
C107-0035 CJM03.5 3.5 mm Jobber Drills Cobalt 3.5 mm 39 70 10 Box
You need to be logged in to see prices.
C107-0040 CJM04.0 4.0 mm Jobber Drills Cobalt 4.0 mm 43 75 10 Box
You need to be logged in to see prices.
C107-0042 CJM04.2 4.2 mm Jobber Drills Cobalt 4.2 mm 43 75 10 Box
You need to be logged in to see prices.
C107-0045 CJM04.5 4.5 mm Jobber Drills Cobalt 4.5 mm 47 80 10 Box
You need to be logged in to see prices.
C107-0048 CJM04.8 4.8 mm Jobber Drills Cobalt 4.8 mm 52 86 10 Box
You need to be logged in to see prices.
C107-0050 CJM05.0 5.0 mm Jobber Drills Cobalt 5.0 mm 52 86 10 Box
You need to be logged in to see prices.
C107-0055 CJM05.5 5.5 mm Jobber Drills Cobalt 5.5 mm 57 93 10 Box
You need to be logged in to see prices.
C107-0060 CJM06.0 6.0 mm Jobber Drills Cobalt 6.0 mm 57 93 10 Box
You need to be logged in to see prices.
C107-0065 CJM06.5 6.5 mm Jobber Drills Cobalt 6.5 mm 63 101 10 Box
You need to be logged in to see prices.
C107-0068 CJM06.8 6.8 mm Jobber Drills Cobalt 6.8 mm 63 101 10 Box
You need to be logged in to see prices.
C107-0070 CJM07.0 7.0 mm Jobber Drills Cobalt 7.0 mm 63 101 10 Box
You need to be logged in to see prices.
C107-0075 CJM07.5 7.5 mm Jobber Drills Cobalt 7.5 mm 69 109 10 Box
You need to be logged in to see prices.
C107-0080 CJM08.0 8.0 mm Jobber Drills Cobalt 8.0 mm 75 117 10 Box
You need to be logged in to see prices.
C107-0085 CJM08.5 8.5 mm Jobber Drills Cobalt 8.5 mm 75 117 10 Box
You need to be logged in to see prices.
C107-0090 CJM09.0 9.0 mm Jobber Drills Cobalt 9.0 mm 81 125 10 Box
You need to be logged in to see prices.
C107-0095 CJM09.5 9.5 mm Jobber Drills Cobalt 9.5 mm 81 125 10 Box
You need to be logged in to see prices.
C107-0100 CJM10.0 10.0 mm Jobber Drills Cobalt 10.0 mm 87 133 10 Box
You need to be logged in to see prices.
C107-0102 CJM10.2 10.2 mm Jobber Drills Cobalt 10.2 mm 87 133 5 Box
You need to be logged in to see prices.
C107-0105 CJM10.5 10.5 mm Jobber Drills Cobalt 10.5 mm 94 142 5 Box
You need to be logged in to see prices.
C107-0110 CJM11.0 11.0 mm Jobber Drills Cobalt 11.0 mm 94 142 5 Box
You need to be logged in to see prices.
C107-0115 CJM11.5 11.5 mm Jobber Drills Cobalt 11.5 mm 94 142 5 Box
You need to be logged in to see prices.
C107-0120 CJM12.0 12.0 mm Jobber Drills Cobalt 12.0 mm 101 151 5 Box
You need to be logged in to see prices.
C107-0125 CJM12.5 12.5 mm Jobber Drills Cobalt 12.5 mm 101 151 5 Box
You need to be logged in to see prices.
C107-0130 CJM13.0 13.0 mm Jobber Drills Cobalt 13.0 mm 101 151 5 Box
You need to be logged in to see prices.
C107-1004 CJF1/16 1/16 inch Jobber Cobalt 1/16 " 20 43 10 Box
You need to be logged in to see prices.
C107-1005 CJF5/64 5/64 inch Jobber Cobalt 5/64 " 24 49 10 Box
You need to be logged in to see prices.
C107-1006 CJF3/32 3/32 inch Jobber Cobalt 3/32 " 30 57 10 Box
You need to be logged in to see prices.
C107-1007 CJF7/64 7/64 inch Jobber Cobalt 7/64 " 33 61 10 Box
You need to be logged in to see prices.
C107-1008 CJF1/8 1/8 inch Jobber Drills Cobalt 1/8 " 36 65 10 Box
You need to be logged in to see prices.
C107-1009 CJF9/64 9/64 inch Jobber Cobalt 9/64 " 39 70 10 Box
You need to be logged in to see prices.
C107-1010 CJF5/32 5/32 inch Jobber Cobalt 5/32 " 43 75 10 Box
You need to be logged in to see prices.
C107-1011 CJF11/64 11/64 inch Jobber Cobalt 11/64 " 47 80 10 Box
You need to be logged in to see prices.
C107-1012 CJF3/16 3/16 inch Jobber Cobalt 3/16 " 52 86 10 Box
You need to be logged in to see prices.
C107-1013 CJF13/64 13/64 inch Jobber Cobalt 13/64 " 52 86 10 Box
You need to be logged in to see prices.
C107-1014 CJF7/32 7/32 inch Jobber Cobalt 7/32 " 57 93 10 Box
You need to be logged in to see prices.
C107-1016 CJF1/4 1/4 inch Jobber Drills Cobalt 1/4 " 63 101 10 Box
You need to be logged in to see prices.
C107-1018 CJF9/32 9/32 inch Jobber Cobalt 9/32 " 69 109 10 Box
You need to be logged in to see prices.
C107-1020 CJF5/16 5/16 inch Jobber Cobalt 5/16 " 75 117 10 Box
You need to be logged in to see prices.
C107-1022 CJF11/32 11/32 inch Jobber Cobalt 11/32 " 81 125 10 Box
You need to be logged in to see prices.
C107-1024 CJF3/8 3/8 inch Jobber Drills Cobalt 3/8 " 87 133 10 Box
You need to be logged in to see prices.
C107-1026 CJF13/32 13/32 inch Jobber Cobalt 13/32 " 87 133 5 Box
You need to be logged in to see prices.
C107-1028 CJF7/16 7/16 inch Jobber Cobalt 7/16 " 94 142 5 Box
You need to be logged in to see prices.
C107-1032 CJF1/2 1/2 inch Jobber Drills Cobalt 1/2 " 101 151 5 Box
You need to be logged in to see prices.
