HSS-Co5 Cobalt Blacksmith Drill Bits (1/2
HSS-Co5 Cobalt Blacksmith Drill Bits (1/2Inch Reduced Shank)

HSS-Co5 Cobalt Blacksmith Drill Bits (1/2" Reduced Shank)

Descriptions

Flute Type
Standard helix,right hand,milled flutes
Point Angle
118°
Shank
1/2"(12.7mm)
Surface Treatment
Straw Finish
Application
Drills in steel, high tensile steel up to 1000N/mm2,stainless steel V2A/V4A, cast steel, cast iron,non-ferrous metals and hard plastics
Manufactured To
BS 328
Material
HSS-Co5

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
5172-0135 PS BLACKSMITH 13.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 13.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0140 PS BLACKSMITH 14.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 14.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0145 PS BLACKSMITH 14.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 14.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0150 PS BLACKSMITH 15.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 15.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0155 PS BLACKSMITH 15.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 15.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0160 PS BLACKSMITH 16.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 16.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0165 PS BLACKSMITH 16.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 16.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0170 PS BLACKSMITH 17.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 17.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0175 PS BLACKSMITH 17.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 17.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0180 PS BLACKSMITH 18.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 18.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0185 PS BLACKSMITH 18.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 18.5mm 80 152 1 Box
You need to be logged in to see prices.
5172-0190 PS BLACKSMITH 19.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 19.0mm 80 152 1 Box
You need to be logged in to see prices.
5172-0195 PS BLACKSMITH 19.5 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 19.5mm 76 152 1 Box
You need to be logged in to see prices.
5172-0200 PS BLACKSMITH 20.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 20.0mm 76 152 1 Box
You need to be logged in to see prices.
5172-0210 PS BLACKSMITH 21.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 21.0mm 76 152 1 Box
You need to be logged in to see prices.
5172-0220 PS BLACKSMITH 22.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 22.0mm 76 152 1 Box
You need to be logged in to see prices.
5172-0230 PS BLACKSMITH 23.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 23.0mm 76 152 1 Box
You need to be logged in to see prices.
5172-0240 PS BLACKSMITH 24.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 24.0mm 76 152 1 Box
You need to be logged in to see prices.
5172-0250 PS BLACKSMITH 25.0 COBALT M35 1/2" PARALLEL SHANK DRILL BIT 25.0mm 76 152 1 Box
You need to be logged in to see prices.
