HSCo8 2 flute Long Series Screwed Shank
HSCo8 2 flute Long Series Screwed Shank

HSCo8 2 flute Long Series Screwed Shank

Descriptions

Shank Type
Screwed parallel shank.
Flute type
30° helix.
Surface Treatment
Bright.
Application
Milling keyways and slots in one cut.Designed for plunging operations.High tensile steels and other difficult materials.
Manufactured To
BS 122
Material
HSCo8

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Shank Type & Diameter Pack Qty Packaged In/On Price
5350-0020 SLD 2FHSCo8 L 2 Threaded Shank 2mm 4mm 51mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5350-0030 SLD 2FHSCo8 L 3 Threaded Shank 3mm 11mm 61mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5350-0040 SLD 2FHSCo8 L 4 Threaded Shank 4mm 13mm 67mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5350-0050 SLD 2FHSCo8 L 5 Threaded Shank 5mm 13mm 76mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5350-0060 SLD 2FHSCo8 L 6 Threaded Shank 6mm 16mm 76mm Screwed 6mm 1 Box
You need to be logged in to see prices.
5350-0080 SLD 2FHSCo8 L 8 Threaded Shank 8mm 19mm 80mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5350-0100 SLD 2FHSCo8 L 10 Threaded Shank 10mm 22mm 83mm Screwed 10mm 1 Box
You need to be logged in to see prices.
5350-0120 SLD 2FHSCo8 L 12 Threaded Shank 12mm 26mm 95mm Screwed 12mm 1 Box
You need to be logged in to see prices.
5350-0160 SLD 2FHSCo8 L 16 Threaded Shank 16mm 32mm 108mm Screwed 16mm 1 Box
You need to be logged in to see prices.
5350-0200 SLD 2FHSCo8 L 20 Threaded Shank 20mm 38mm 121mm Screwed 16mm 1 Box
