BSPF(G) Die Nuts
BSPF(G) Die Nuts

BSPF(G) Die Nuts

Descriptions

Type of Thread
British standard pipe.
Fastening G-series
Tolerance
Class B
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6312-0200 HSS 1/8x28TPIx.920 BSPF G DIENUTS Brooke 1/8" 28 1 Box 18.25mm
You need to be logged in to see prices.
6312-0201 HSS 1/4x19TPIx1.100 BSPF G DIENUTS Brooke 1/4" 19 1 Box 18.25mm
You need to be logged in to see prices.
6312-0202 HSS 3/8x19TPIx1.300 BSPF G DIENUTS Brooke 3/8" 19 1 Box 23.50mm
You need to be logged in to see prices.
6312-0203 HSS 1/2x14TPIx1.670 BSPF G DIENUTS Brooke 1/2" 14 1 Box 28.0mm
You need to be logged in to see prices.
6312-0204 HSS 5/8x14TPIx1.670 BSPF G DIE NUT Brooke 5/8" 14 1 Box 33.50mm
You need to be logged in to see prices.
6312-0205 HSS 3/4x14TPIx2.050 BSPF G DIENUTS Brooke 3/4" 14 1 Box 38.0mm
You need to be logged in to see prices.
6312-0207 HSS 1 inch x11TPIx2.580 BSPF G DIENUTS Brooke 1" 11 1 Box 52.0mm
