BSF Die Nuts
BSF Die Nuts

BSF Die Nuts

Descriptions

Type of Thread
British standard fine
Tolerance
Medium bolt
Surface Treatment
Bright
Application
For threading steel, some stainless steels, cast irons and non-ferrous materials such as Aluminium & Brass.
Manufactured To
BS 1127:1950
Material
HSS

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Pitch (mm) Pack Qty Packaged In/On Across Flats Price
6272-0202 HSS 1/4x26TPIx.710 BSF DIENUTS Brooke 1/4" 26 1 Box 18.25mm
You need to be logged in to see prices.
6272-0203 HSS 5/16x22TPIx.820 BSF DIENUTS Brooke 5/16" 22 1 Box 21.0mm
You need to be logged in to see prices.
6272-0204 HSS 3/8x20TPIx.920 BSF DIENUTS Brooke 3/8" 20 1 Box 23.50mm
You need to be logged in to see prices.
6272-0206 HSS 1/2x16TPIx1.100 BSF DIENUTS Brooke 1/2" 16 1 Box 28.0mm
You need to be logged in to see prices.
6272-0208 HSS 5/8x14TPIx1.300 BSF DIENUTS Brooke 5/8" 14 1 Box 33.50mm
You need to be logged in to see prices.
6272-0210 HSS 3/4x12TPIx1.480 BSF DIENUTS Brooke 3/4" 12 1 Box 38.0mm
You need to be logged in to see prices.
6272-0212 HSS 1"x10TPI BSF Dienut x2.050 Brooke 1" 10 1 Box 52.0mm
You need to be logged in to see prices.
6272-0214 HSS 1.1/4x9TPIx2.220 BSF DIENUTS Brooke 1.1/4" 9 1 Box 57.0mm
You need to be logged in to see prices.
6272-0216 HSS 1.1/2x8TPIx2.760 BSF DIENUTS Brooke 1.1/2" 8 1 Box 70.0mm
You need to be logged in to see prices.
