HSS-G TiN Coated Jobber Drill Bits Boxed
HSS-G TiN Coated Jobber Drill Bits Boxed

HSS-G TiN Coated Jobber Drill Bits Boxed

Descriptions

Flute Type
Standard helix,right hand,ground flutes
Point Angle
135° split point
Surface Treatment
TiN coated increases tool life & performance.
Application
Drills in steel, high tensile steel up to 900N/mm2, cast steel, cast iron, non-ferrous metals and hard plastics. Compared to traditional HSS jobber drill bits, speed can be increased by 40 -60% and feed by 10 -20% without reducing the life time of the drill bit significantly. TiN is also a poor conductor of heat, so the heat generated during the drilling process is diverted into the chips and coolant and less into the drill bit.
Manufactured To
Din 338
Material
HSS
PLEASE NOTE: Prices are per drill not pack Qty.

There are no downloads for this product.

You need to be logged in to see prices.
Code Description Diameter Flute Length (mm) Overall Length (mm) Pack Qty Packaged In/On Price
C105-0010 1.00 mm HSS TiN Coated Metric Drill - Premium 1.00mm 12 34 10 Box
You need to be logged in to see prices.
C105-0015 1.50 mm HSS TiN Coated Metric Drill - Premium 1.50mm 18 40 10 Box
You need to be logged in to see prices.
C105-0020 2.00 mm HSS TiN Coated Metric Drill - Premium 2.00mm 24 49 10 Box
You need to be logged in to see prices.
C105-0025 2.50 mm HSS TiN Coated Metric Drill - Premium 2.50mm 30 57 10 Box
You need to be logged in to see prices.
C105-0030 3.00 mm HSS TiN Coated Metric Drill - Premium 3.00mm 33 61 10 Box
You need to be logged in to see prices.
C105-0032 3.20 mm HSS TiN Coated Metric Drill - Premium 3.20mm 36 65 10 Box
You need to be logged in to see prices.
C105-0033 3.30 mm HSS TiN Coated Metric Drill - Premium 3.30mm 36 65 10 Box
You need to be logged in to see prices.
C105-0035 3.50 mm HSS TiN Coated Metric Drill - Premium 3.50mm 39 70 10 Box
You need to be logged in to see prices.
C105-0040 4.00 mm HSS TiN Coated Metric Drill - Premium 4.00mm 43 75 10 Box
You need to be logged in to see prices.
C105-0042 4.20 mm HSS TiN Coated Metric Drill - Premium 4.20mm 43 75 10 Box
You need to be logged in to see prices.
C105-0045 4.50 mm HSS TiN Coated Metric Drill - Premium 4.50mm 47 80 10 Box
You need to be logged in to see prices.
C105-0048 4.80 mm HSS TiN Coated Metric Drill - Premium 4.80mm 52 86 10 Box
You need to be logged in to see prices.
C105-0050 5.00 mm HSS TiN Coated Metric Drill - Premium 5.00mm 52 86 10 Box
You need to be logged in to see prices.
C105-0055 5.50 mm HSS TiN Coated Metric Drill - Premium 5.50mm 57 93 10 Box
You need to be logged in to see prices.
C105-0060 6.00 mm HSS TiN Coated Metric Drill - Premium 6.00mm 57 93 10 Box
You need to be logged in to see prices.
C105-0065 6.50 mm HSS TiN Coated Metric Drill - Premium 6.50mm 63 101 10 Box
You need to be logged in to see prices.
C105-0068 6.80 mm HSS TiN Coated Metric Drill - Premium 6.80mm 63 101 10 Box
You need to be logged in to see prices.
C105-0070 7.00 mm HSS TiN Coated Metric Drill - Premium 7.00mm 63 101 10 Box
You need to be logged in to see prices.
C105-0075 7.50 mm HSS TiN Coated Metric Drill - Premium 7.50mm 69 109 10 Box
You need to be logged in to see prices.
C105-0080 8.00 mm HSS TiN Coated Metric Drill - Premium 8.00mm 75 117 10 Box
You need to be logged in to see prices.
C105-0085 8.50 mm HSS TiN Coated Metric Drill - Premium 8.50mm 75 117 10 Box
You need to be logged in to see prices.
C105-0090 9.00 mm HSS TiN Coated Metric Drill - Premium 9.00mm 81 125 10 Box
You need to be logged in to see prices.
C105-0095 9.50 mm HSS TiN Coated Metric Drill - Premium 9.50mm 81 125 10 Box
You need to be logged in to see prices.
C105-0100 10.00 mm HSS TiN Coated Metric Drill - Premium 10.00mm 87 133 5 Box
You need to be logged in to see prices.
C105-0102 10.20 mm HSS TiN Coated Metric Drill - Premium 10.20mm 87 133 5 Box
You need to be logged in to see prices.
C105-0105 10.50 mm HSS TiN Coated Metric Drill - Premium 10.50mm 94 142 5 Box
You need to be logged in to see prices.
C105-0110 11.00 mm HSS TiN Coated Metric Drill - Premium 11.00mm 94 142 5 Box
You need to be logged in to see prices.
C105-0115 11.50 mm HSS TiN Coated Metric Drill - Premium 11.50mm 94 142 5 Box
You need to be logged in to see prices.
C105-0120 12.00 mm HSS TiN Coated Metric Drill - Premium 12.00mm 101 151 5 Box
You need to be logged in to see prices.
C105-0125 12.50 mm HSS TiN Coated Metric Drill - Premium 12.50mm 101 151 5 Box
You need to be logged in to see prices.
C105-0130 13.00 mm HSS TiN Coated Metric Drill - Premium 13.00mm 101 151 5 Box
You need to be logged in to see prices.
